Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 15, 2018, 08:16 AM

  • 22 0973_22 0972_15082018_013955.mp4

Date
08/15/2018
W/O
717737
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00790
PipeID
P17343
Time
1:16 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5901
Sewer Name
22 BASE LINE TRUNK
City
GLENDORA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
12
Purpose
Routine Assessment
Project
WO_717737_TV22002_AUG2018
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
22 0972
Downstream MH
22 0973
Dir. of Survey
Upstream
Length Surveyed
228.4 ft.
Total Length
228.4 ft.
Structural Index
3
Structural Quick
3H00
Structural Rating
135
O&M Index
2
O&M Quick
2H00
O&M Rating
90
Overall Index
3
Overall Quick
—
Overall Rating
225
Pipe schematic from manhole 22 0972 to 22 0973
MH: 22 0972MH: 22 0973upstream0 ft. AMH - Upstream Manhole, Survey Ends - 22 09730.2 ft. MGO - General Observation - COCKROACHES IN MANHOLE0.2 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0.2 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish0.2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish19.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"39.9 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: NO, 6"83.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"106.2 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"110.8 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"141.1 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"173.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"207.3 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"226.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start226.4 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start228.4 ft. MWM - Water Mark, 25 %of cross sectional area228.4 ft. AMH - Downstream Manhole, Survey Begins - 22 0972228.4 ft. MWL - Water Level, 10 %of cross sectional area228.4 ft. MGO - General Observation - COCKROACHES IN MANHOLE

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P17343Work order 717737

Observations (19)

DistanceCodeObservation
144.9TFC—
55.2TFC—
228.2MGOCOCKROACHES IN MANHOLE
87.3TFC—
0MWM—
208.7TFC—
21.1TFA—
0AMH22 0972
188.5TB—
2DAGS—
228.4AMH22 0973
228.2MGOCONNECTION AT MH 9 O'CLOCK
2SAV—
0MWL—
117.6TBA—
228.2SAV—
228.2DAGS—
122.2TBA—
0MGOCOCKROACHES IN MANHOLE

Properties (6)

additional_info
SC364770
custom_field_two
3
customer
LACSD
datetime
2018-08-15T01:16:53-07:00
documentation
PRO PIPE
is_lateral_inspection
false
