Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 2, 2016, 08:09 AM

  • 02 0113_02 0113_110216_012947.mp4

Date
11/02/2016
W/O
602602
Weather
Dry
Operator/Surveyor
J. HARTOOG
Sewer ID
Z00237
PipeID
P02280
Time
1:09 AM
Certificate
U-507-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3754
Sewer Name
02 BELLFLOWER TRUNK
City
BELLFLOWER, CA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
36
Purpose
Routine Assessment
Project
WO_602602_TV02019_NOV2016
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
02 0112
Downstream MH
02 0113
Dir. of Survey
Upstream
Length Surveyed
312.1 ft.
Total Length
312.2 ft.
Structural Index
3
Structural Quick
4131
Structural Rating
10
O&M Index
2
O&M Quick
2L00
O&M Rating
130
Overall Index
2
Overall Quick
—
Overall Rating
140
Pipe schematic from manhole 02 0112 to 02 0113
MH: 02 0112MH: 02 0113upstream0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Ends - 02 01130 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK2.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish52.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"79 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4" - W/ DEBRIS84.9 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 4"108.2 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 4"125.8 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"126.1 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: NO127.7 ft. CM - Crack Multiple, from 02 to 04 o'clock, within 8 inches of joint: YES152.5 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 4"176.5 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"176.8 ft. CC - Crack Circumferential, from 02 to 03 o'clock, within 8 inches of joint: NO196.7 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 4"202.5 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"226.1 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 4"228.3 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: NO, 4"252.4 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 4"272.4 ft. DSF - Deposits Settled Fine, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish285.3 ft. DSF - Deposits Settled Fine, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start285.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"302.3 ft. FM - Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES310.1 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start312.2 ft. AMH - Downstream Manhole, Survey Begins - 02 0112312.2 ft. MWL - Water Level, 5 %of cross sectional area312.2 ft. MWM - Water Mark, 15 %of cross sectional area

Observation photos (7)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES

    9.9 ft. - Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES

  • Deposits Settled Fine, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start

    26.9 ft. - Deposits Settled Fine, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start

  • Crack Circumferential, from 02 to 03 o'clock, within 8 inches of joint: NO

    135.4 ft. - Crack Circumferential, from 02 to 03 o'clock, within 8 inches of joint: NO

  • Crack Multiple, from 02 to 04 o'clock, within 8 inches of joint: YES

    184.5 ft. - Crack Multiple, from 02 to 04 o'clock, within 8 inches of joint: YES

  • Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: NO

    186.1 ft. - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: NO

  • Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4" - W/ DEBRIS

    233.2 ft. - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4" - W/ DEBRIS

All inspections of P02280Work order 602602

Observations (27)

DistanceCodeObservation
186.1FC—
312.2MGOCONNECTION AT MH 9 O'CLOCK
310.1DAGS—
233.2TFW/ DEBRIS
39.8DSF—
0AMH02 0112
0MWL—
86.1TFA—
312.2AMH02 0113
260TFC—
227.3TF—
312.2MGOCONNECTION AT MH 3 O'CLOCK
0MWM—
9.9FM—
186.4TF—
204TFA—
2.1DAGS—
59.8TFA—
135.7TF—
115.5TF—
83.9TFA—
109.7TF—
135.4CC—
159.7TFA—
26.8TF—
26.9DSF—
184.5CM—

Properties (6)

additional_info
SC303746
custom_field_two
2
customer
LACSD
datetime
2016-11-02T01:09:00-07:00
documentation
PRO-PIPE
is_lateral_inspection
false
