Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 28, 2016, 06:57 AM

  • 14 0231A_14 0231_27012016_225538.mp4

Date
01/27/2016
W/O
547072
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00575
PipeID
P18282
Time
10:57 PM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3085
Sewer Name
14 NORTH SIDE TRUNK
City
LANCASTER
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 14
Page No.
04
Purpose
Routine Assessment
Project
RFIR_WO_547072_TV14057_JAN2016
Sewer Type
GRAVITY
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
14 0231A
Downstream MH
14 0231
Dir. of Survey
Downstream
Length Surveyed
150.2 ft.
Total Length
150.2 ft.
Structural Index
2
Structural Quick
3312
Structural Rating
11
O&M Index
2
O&M Quick
2100
O&M Rating
2
Overall Index
2
Overall Quick
—
Overall Rating
13
Pipe schematic from manhole 14 0231A to 14 0231
MH: 14 0231AMH: 14 0231downstream0 ft. MWM - Water Mark, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 14 0231A0 ft. MWL - Water Level, 5 %of cross sectional area - NO FLOW.16.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"27.3 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES51.4 ft. JAM - Joint Angular Medium57.5 ft. JSM - Joint Separated Medium73.4 ft. CM - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES74.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"136.2 ft. CM - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES137.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"147.9 ft. OBZ - Obstacles Other, 10 %of cross sectional area, from 05 to 07 o'clock - REBAR150.2 ft. MSA - Survey Abandoned - DUE TO OBSTACLE

Observation photos (8)

  • Water Level, 5 %of cross sectional area - NO FLOW.

    0 ft. - Water Level, 5 %of cross sectional area - NO FLOW.

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    27.3 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Joint Angular Medium

    51.4 ft. - Joint Angular Medium

  • Joint Separated Medium

    57.5 ft. - Joint Separated Medium

  • Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

    73.4 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

    136.2 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

  • Obstacles Other, 10 %of cross sectional area, from 05 to 07 o'clock - REBAR

    147.9 ft. - Obstacles Other, 10 %of cross sectional area, from 05 to 07 o'clock - REBAR

  • Survey Abandoned - DUE TO OBSTACLE

    150.2 ft. - Survey Abandoned - DUE TO OBSTACLE

All inspections of P18282Work order 547072

Observations (13)

DistanceCodeObservation
147.9OBZREBAR
57.5JSM—
136.2CM—
0MWM—
27.3CM—
73.4CM—
137.5TFC—
16.6TFC—
0AMH14 0231A
0MWLNO FLOW.
150.2MSADUE TO OBSTACLE
74.7TFC—
51.4JAM—

Properties (6)

additional_info
SC225463
custom_field_two
5
customer
LACSD
datetime
2016-01-27T22:57:03-08:00
documentation
PRO PIPE
is_lateral_inspection
false
