Wastewater/Activity/PacpInspection/1.0Jan 14, 2016, 11:09 AM
02 1843_02 1842_20160114_034500_.mp4
- Date
- 01/14/2016
- W/O
- 547054
- Weather
- Dry
- Operator/Surveyor
- N.ZAHREDDINE
- Sewer ID
- Z00283
- PipeID
- P04188
- Time
- 3:09 AM
- Certificate
- U-109-7948
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3157
- Sewer Name
- 02 MONTEBELLO INTERCEPTOR TRUNK, SECTS 1&2
- City
- COMMERCE
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 17
- Purpose
- Routine Assessment
- Project
- RFIR_WO_547054_TV02213_JAN2016
- Sewer Type
- GRAVITY
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 30 in.
- Upstream MH
- 02 1843
- Downstream MH
- 02 1842
- Dir. of Survey
- Downstream
- Length Surveyed
- 513.1 ft.
- Total Length
- 513.1 ft.
- Structural Index
- 5
- Structural Quick
- 5100
- Structural Rating
- 5
- O&M Index
- 2
- O&M Quick
- 4112
- O&M Rating
- 6
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 11
Observation photos (2)
4 ft. - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"
108.8 ft. - Surface Reinforcement Corroded, from 09 to 10 o'clock, within 8 inches of joint: YES
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 510.2 | MGO | MAGNEZIUM H.O. 40% FINISH |
| 513.1 | AMH | 02 1842 |
| 19.2 | LR | — |
| 0 | MWM | — |
| 108.8 | SRC | — |
| 0 | MWL | — |
| 7.5 | MGO | MAGNEZIUM H.O. 40% START |
| 4 | TFA | — |
| 171 | LL | — |
| 0 | AMH | 02 1843 |
Properties (6)
- additional_info
- SC224968
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-01-14T03:09:55-08:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
