  • 18 0469_18 0468._20160111_051547_.mp4

Date
01/11/2016
W/O
547052
Weather
Dry
Operator/Surveyor
R.VARGAS
Sewer ID
Z00691
PipeID
P14323
Time
4:03 AM
Certificate
U-209-211
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3031
Sewer Name
18 NORTH OUTFALL TRUNK
City
WHITTIER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
14
Purpose
V
Project
RFIR_WO_547052_TV18140_JAN2016
Sewer Type
SS
Material
NRCP
Shape
Circular
Height
21 in.
Upstream MH
18 0468.
Downstream MH
18 0469
Dir. of Survey
Upstream
Length Surveyed
120.7 ft.
Total Length
120.7 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
2
O&M Quick
4121
O&M Rating
8
Overall Index
2
Overall Quick
—
Overall Rating
11
Pipe schematic from manhole 18 0468. to 18 0469
MH: 18 0468.MH: 18 0469upstream0 ft. OBR - Obstacles Rocks, 25 %of cross sectional area, from 04 to 08 o'clock - MAG0 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish0 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish0 ft. MGO - General Observation - MAGNESIUM H.O. FINISH0 ft. MSA - Survey Abandoned - MAG39.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6"39.9 ft. VC - Vermin Cockroach43.9 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"96.5 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 4"103.9 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"118.7 ft. MGO - General Observation - MAGNESIUM H.O. START118.7 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start118.7 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start120.7 ft. MWL - Water Level, 15 %of cross sectional area120.7 ft. MGO - Reversal Inspection120.7 ft. VC - Vermin Cockroach120.7 ft. AMH - Downstream Manhole, Survey Begins - 18 0468120.7 ft. MWM - Water Mark, 25 %of cross sectional area

Observation photos (3)

  • General Observation - MAGNESIUM H.O. START

    2 ft. - General Observation - MAGNESIUM H.O. START

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish

    120.7 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish

All inspections of P14323Work order 547052

Observations (18)

DistanceCodeObservation
2MGOMAGNESIUM H.O. START
0MWL—
0MGO—
16.8TFA—
24.2TFA—
0VC—
120.7OBRMAG
76.8TFA—
80.8TF—
2SAV—
2DAGS—
120.7SAV—
120.7DAGS—
120.7MGOMAGNESIUM H.O. FINISH
120.7MSAMAG
80.8VC—
0AMH18 0468
0MWM—

Properties (6)

additional_info
SC224625
custom_field_two
3
customer
LACSD
datetime
2016-01-11T04:03:32-08:00
documentation
PRO PIPE
is_lateral_inspection
false
