Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 3, 2016, 08:21 AM

  • 29 0340_29 0338_20160303_014135.mp4

Date
03/03/2016
W/O
557696
Weather
Dry
Operator/Surveyor
J. HARTOOG
Sewer ID
Z01017
PipeID
P24360
Time
12:21 AM
Certificate
U507-03-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3216
Sewer Name
29 PACIFIC COAST HIGHWAY SEWER
City
SIGNAL HILL
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
03
Purpose
Routine Assessment
Project
WO_557696_TV29045_2016MAR
Sewer Type
GRAVITY
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Upstream MH
29 0340
Downstream MH
29 0338
Dir. of Survey
Downstream
Length Surveyed
246 ft.
Total Length
246 ft.
Structural Index
3
Structural Quick
4137
Structural Rating
25
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
25
Pipe schematic from manhole 29 0340 to 29 0338
MH: 29 0340MH: 29 0338downstream0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 29 03400 ft. MWM - Water Mark, 10 %of cross sectional area12.3 ft. CM - Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES12.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 4"27.8 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: NO, 4"35.2 ft. TFC - Tap Factory Made Capped, at 03 o'clock, -, within 8 inches of joint: NO, 4"64.1 ft. TFC - Tap Factory Made Capped, at 09 o'clock, -, within 8 inches of joint: NO, 4"92.7 ft. TBA - Tap Break-In Active, at 02 o'clock, -, within 8 inches of joint: YES, 4"112.7 ft. TFC - Tap Factory Made Capped, at 09 o'clock, -, within 8 inches of joint: NO, 4"140.6 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: NO, 4"152.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"161.6 ft. FM - Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES162.3 ft. TFC - Tap Factory Made Capped, at 09 o'clock, -, within 8 inches of joint: NO, 4"206.7 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"208.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"218.8 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES223 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start245.7 ft. CM - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish246 ft. AMH - Downstream Manhole, Survey Ends - 29 0338

Observation photos (3)

  • Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES

    12.3 ft. - Crack Multiple, from 09 to 12 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES

    161.6 ft. - Fracture Multiple, from 09 to 02 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    223 ft. - Crack Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

All inspections of P24360Work order 557696

Observations (20)

DistanceCodeObservation
35.2TFC—
245.7CM—
218.8CM—
152.2TFC—
206.7TFC—
208.9TFC—
27.8TFA—
12.7TFC—
246AMH29 0338
223CM—
64.1TFC—
0MWL—
140.6TFA—
0AMH29 0340
162.3TFC—
92.7TBA—
161.6FM—
0MWM—
112.7TFC—
12.3CM—

Properties (6)

additional_info
SC305305
custom_field_two
3
customer
LACSD
datetime
2016-03-03T00:21:00-08:00
documentation
PRO-PIPE
is_lateral_inspection
false
