01 0133_01 0132_16122015_003834.mp4
- Date
- 12/16/2015
- W/O
- 524985
- Weather
- Dry
- Operator/Surveyor
- M.MARTINEZ
- Sewer ID
- Z00204
- PipeID
- P02077
- Time
- 12:37 AM
- Certificate
- 12345
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K2963
- Sewer Name
- 01 COMPTON CREEK EXTENSION TRUNK, SECTION 2
- City
- COMPTON
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 12
- Purpose
- Routine Assessment
- Project
- WO_524985_TV011104_NOV2015
- Sewer Type
- GRAVITY
- Material
- Vitrified Clay Pipe
- Lining Method
- Segmented Panel
- Shape
- Circular
- Height
- 15 in.
- Upstream MH
- 01 0133
- Downstream MH
- 01 0132
- Dir. of Survey
- Downstream
- Length Surveyed
- 175 ft.
- Total Length
- 175 ft.
- Structural Index
- 2
- Structural Quick
- 332B
- Structural Rating
- 35
- O&M Index
- 3
- O&M Quick
- 413F
- O&M Rating
- 106
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 141
Observation photos (14)
16.3 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES
21.2 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES
31.3 ft. - Crack Spiral, from 01 to 02 o'clock, within 8 inches of joint: YES
42 ft. - Crack Spiral, from 07 to 12 o'clock, within 8 inches of joint: YES
52.3 ft. - Crack Spiral, from 01 to 04 o'clock, within 8 inches of joint: YES
56.3 ft. - Crack Longitudinal, at 01 o'clock, within 8 inches of joint: YES
71.1 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES
91 ft. - Crack Spiral, from 01 to 03 o'clock, within 8 inches of joint: YES
91 ft. - Crack Longitudinal, at 11 o'clock, within 8 inches of joint: YES
96.3 ft. - Crack Multiple, from 10 to 11 o'clock, within 8 inches of joint: YES
101.5 ft. - Crack Spiral, from 01 to 03 o'clock, within 8 inches of joint: YES
112.6 ft. - Crack Spiral, from 07 to 03 o'clock, within 8 inches of joint: YES
126.8 ft. - Crack Multiple, from 01 to 02 o'clock, within 8 inches of joint: YES
133.2 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: YES
Observations (22)
| Distance | Code | Observation |
|---|---|---|
| 31.3 | CS | — |
| 0 | AMH | 01 0133 |
| 3.3 | DAGS | — |
| 56.3 | CL | — |
| 71.1 | CL | — |
| 91 | CS | — |
| 0 | MWL | — |
| 21.2 | CL | — |
| 52.3 | CS | — |
| 42 | CS | — |
| 96.3 | CM | — |
| 112.6 | CS | — |
| 101.5 | CS | — |
| 133.2 | CL | — |
| 77 | CL | — |
| 16.3 | CL | — |
| 175 | AMH | 01 0132 |
| 126.8 | CM | — |
| 172.9 | DAGS | — |
| 81.4 | CM | — |
| 0 | MWM | — |
| 91 | CL | — |
Properties (6)
- additional_info
- SC224802
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2015-12-16T00:37:31-08:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
