Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 18, 2018, 11:35 AM

  • Section#4_02 2326_02 1768__9182018__I0070.mp4

Date
09/18/2018
W/O
0730104
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00271
PipeID
P04116
Time
4:35 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Heavy Cleaning
Media Label
I0070
Sewer Name
02 INDIANA STREET TRUNK
City
LOS ANGLES
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
11A
Purpose
Maintenance Related
Project
20180918MDM_INDIANA_STREET_TRUNK
Material
NRCP
Shape
Circular
Height
7.489999771118164 in.
Upstream MH
02 1768
Downstream MH
02 2326
Dir. of Survey
Upstream
Length Surveyed
39.2 ft.
Total Length
39.2 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 02 1768 to 02 2326
MH: 02 1768MH: 02 2326upstream0 ft. AMH - Upstream Manhole, Survey Ends - 4:45AM-STOPLOG IN PLACE30.8 ft. MGO - General Observation - 7.49" NRCP-CIPP39.2 ft. MWL - Water Level, 0 %of cross sectional area - NO FLOW39.2 ft. AMH - Downstream Manhole, Survey Begins - 4:40AM39.2 ft. MWM - Water Mark, 10 %of cross sectional area

Observation photos (2)

  • General Observation - 7.49" NRCP-CIPP

    8.4 ft. - General Observation - 7.49" NRCP-CIPP

  • Upstream Manhole, Survey Ends - 4:45AM-STOPLOG IN PLACE

    39.2 ft. - Upstream Manhole, Survey Ends - 4:45AM-STOPLOG IN PLACE

All inspections of P04116Work order 0730104

Observations (5)

DistanceCodeObservation
39.2AMH4:45AM-STOPLOG IN PLACE
8.4MGO7.49" NRCP-CIPP
0MWLNO FLOW
0AMH4:40AM
0MWM—

Properties (4)

customer
LACSD
datetime
2018-09-18T04:35:00-07:00
documentation
MARTIN,REVELES,OLIVER 111,BRAR
is_lateral_inspection
false
