Wastewater/Activity/PacpInspection/1.0Mar 6, 2018, 06:20 AM
01 0077_01 0076_05032018_232511.mp4
- Date
- 03/05/2018
- W/O
- 691313
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00209
- PipeID
- P00746
- Time
- 10:20 PM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5473
- Sewer Name
- 01 HOOPER AVENUE-COMPTON CREEK TRUNK
- City
- LOS ANGELES
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 06
- Purpose
- Routine Assessment
- Project
- WO_691313_TV01255_MAR2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 01 0077
- Downstream MH
- 01 0076
- Dir. of Survey
- Downstream
- Length Surveyed
- 85.9 ft.
- Total Length
- 85.9 ft.
- Structural Index
- 3
- Structural Quick
- 3A21
- Structural Rating
- 38
- O&M Index
- 3
- O&M Quick
- 4121
- O&M Rating
- 6
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 44
Observation photos (2)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
23 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 84.1 | DAGS | — |
| 23 | CM | — |
| 0 | MWM | — |
| 84.1 | CM | — |
| 2 | DAGS | — |
| 2 | SSS | — |
| 84.1 | MGO | COCKROACHES IN MANHOLE |
| 85.9 | AMH | 01 0076 |
| 84 | SSS | — |
| 0 | AMH | 01 0077 |
Properties (6)
- additional_info
- SC358479
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-03-05T22:20:03-08:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
