Wastewater/Activity/PacpInspection/1.0Mar 13, 2018, 08:34 AM
05 1094_05 1093_13032018_015053.mp4
- Date
- 03/13/2018
- W/O
- 690188
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00488
- PipeID
- P06328
- Time
- 1:34 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5482
- Sewer Name
- 05 MONETA EXTENSION TRUNK, SECTION 1
- City
- GARDENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 18
- Purpose
- Routine Assessment
- Project
- WO_690188_TV05328_MAR2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Width
- 12 in.
- Upstream MH
- 05 1094
- Downstream MH
- 05 1093
- Dir. of Survey
- Downstream
- Length Surveyed
- 321.3 ft.
- Total Length
- 321.3 ft.
- Structural Index
- 3
- Structural Quick
- 413L
- Structural Rating
- 196
- O&M Index
- 2
- O&M Quick
- 412L
- O&M Rating
- 132
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 328
Observation photos (4)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
5.2 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
129.8 ft. - Fracture Spiral, from 07 to 12 o'clock, within 8 inches of joint: YES
310.5 ft. - Fracture Multiple, from 02 to 05 o'clock, within 8 inches of joint: YES
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 225.5 | TFA | — |
| 24.4 | TFA | — |
| 0 | AMH | 05 1094 |
| 310.5 | FM | — |
| 5.2 | CM | — |
| 318 | CM | — |
| 0 | MWL | — |
| 125.6 | TFA | — |
| 321.3 | AMH | 05 1093 |
| 2 | DAGS | — |
| 129.8 | FS | — |
| 0 | MWM | — |
| 321.3 | DAGS | — |
Properties (6)
- additional_info
- SC358488
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-03-13T01:34:30-07:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
