Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 24, 2018, 12:40 PM

  • B 0376A_B 0376_3242018_064802.mp4

Date
03/24/2018
W/O
0686844
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00091
PipeID
P08889
Time
5:40 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
HO789
Sewer Name
B JOINT OUTFALL B - UNIT 5A
City
TEMPLE CITY
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
10
Purpose
Routine Assessment
Project
20180324MDM_JOINT_OUTFALL_B_UNIT_5A
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Upstream MH
B 0376
Downstream MH
B 0376A
Dir. of Survey
Upstream
Length Surveyed
30.6 ft.
Total Length
30.6 ft.
Structural Index
3
Structural Quick
3121
Structural Rating
5
O&M Index
5
O&M Quick
5100
O&M Rating
5
Overall Index
3
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole B 0376 to B 0376A
MH: B 0376MH: B 0376Aupstream0 ft. AMH - Downstream Manhole, Survey Ends - 6:55AM0.6 ft. SAV - Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: YES, Finish - SEVERE AGG SPORATIC0.6 ft. SSS - Surface Spalling, from 10 to 02 o'clock, within 8 inches of joint: YES, Finish - BLISTERING CONCRETE0.6 ft. MGO - General Observation - MH CONN 3:00 ACTIVE28.6 ft. SAV - Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG SPORATIC28.6 ft. SSS - Surface Spalling, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE30.6 ft. MGO - General Observation - MH CONN 3:00 ACTIVE30.6 ft. MGO - General Observation - MH CONN 9:00 OPEN30.6 ft. MWM - Water Mark, 80 %of cross sectional area30.6 ft. AMH - Upstream Manhole, Survey Begins - 6:45AM30.6 ft. MWL - Water Level, 20 %of cross sectional area

Observation photos (3)

  • Water Mark, 80 %of cross sectional area

    0 ft. - Water Mark, 80 %of cross sectional area

  • Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG SPORATIC

    2 ft. - Surface Aggregate Visible, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - SEVERE AGG SPORATIC

  • Surface Spalling, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE

    2 ft. - Surface Spalling, from 10 to 02 o'clock, within 8 inches of joint: YES, Start - BLISTERING CONCRETE

All inspections of P08889Work order 0686844

Observations (11)

DistanceCodeObservation
0MGOMH CONN 3:00 ACTIVE
2SAVSEVERE AGG SPORATIC
30SAVSEVERE AGG SPORATIC
30SSSBLISTERING CONCRETE
0MGOMH CONN 9:00 OPEN
30.6AMH6:55AM
0MWM—
2SSSBLISTERING CONCRETE
0AMH6:45AM
0MWL—
30MGOMH CONN 3:00 ACTIVE

Properties (6)

custom_field_three
BLISTERING CONCRETE SEVERE AGG VISIBLE SPORATIC
custom_field_two
4
customer
LACSD
datetime
2018-03-24T05:40:23-07:00
documentation
MARTIN,MANANES,REVELES,OLIVER 111
is_lateral_inspection
false
