Wastewater/Activity/PacpInspection/1.0Jun 26, 2018, 10:53 AM
32 0069_32 0068 _26062018_040638.mp4
- Date
- 06/26/2018
- W/O
- 711967
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00886
- PipeID
- P19833
- Time
- 3:53 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5751
- Sewer Name
- 32 CASTAIC TRUNK
- City
- CASTAIC
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 32
- Page No.
- 01
- Purpose
- Routine Assessment
- Project
- WO_711967_TV32047_JUL2018
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 32 0068
- Downstream MH
- 32 0069
- Dir. of Survey
- Upstream
- Length Surveyed
- 193.3 ft.
- Total Length
- 193.3 ft.
- Structural Index
- 3
- Structural Quick
- 3200
- Structural Rating
- 6
- O&M Index
- 2
- O&M Quick
- 2G00
- O&M Rating
- 76
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 82
Observation photos (4)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
73.9 ft. - Fracture Spiral, from 10 to 03 o'clock, within 8 inches of joint: YES
90.1 ft. - Lining Change, Other (enter details in Field 39) - SPOT LINER
117.8 ft. - Fracture Spiral, from 10 to 02 o'clock, within 8 inches of joint: YES
Observations (10)
| Distance | Code | Observation |
|---|---|---|
| 2 | DAGS | — |
| 90.1 | MLC | SPOT LINER |
| 193.3 | AMH | 32 0069 |
| 190.9 | DAGS | — |
| 0 | MWL | — |
| 193.3 | MGO | COCKROACHES IN MANHOLE |
| 0 | AMH | 32 0068 |
| 73.9 | FS | — |
| 0 | MWM | — |
| 117.8 | FS | — |
Properties (7)
- additional_info
- SC359717
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2018-06-26T03:53:46-07:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
- year_laid
- 27282
