  • 18 0932_18 0931 _27062018_232754.mp4

Date
06/27/2018
W/O
711900
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00700
PipeID
P14780
Time
11:13 PM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5758
Sewer Name
18 SCOTT AVENUE TRUNK
City
WHITTIER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
21
Purpose
Routine Assessment
Project
WO_711900_TV18047_JUL2018
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Width
8 in.
Upstream MH
18 0932
Downstream MH
18 0931
Dir. of Survey
Downstream
Length Surveyed
264.5 ft.
Total Length
264.5 ft.
Structural Index
3
Structural Quick
413G
Structural Rating
124
O&M Index
1
O&M Quick
1200
O&M Rating
2
Overall Index
3
Overall Quick
—
Overall Rating
126
Pipe schematic from manhole 18 0932 to 18 0931
MH: 18 0932MH: 18 0931downstream0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 18 09320 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK16.4 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES35.9 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"37.3 ft. FM - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES38.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"67.7 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start70.1 ft. RFL - Roots Fine Lateral, at 02 o'clock70.1 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"82.1 ft. RFJ - Roots Fine Joint, from 08 to 05 o'clock, within 8 inches of joint: YES83.9 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"86.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"134.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"137.6 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"159.5 ft. TS - Tap Saddle, at 02 o'clock, -, within 8 inches of joint: NO, 6"185.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"188.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"233.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"236.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"264.5 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish264.5 ft. AMH - Downstream Manhole, Survey Ends - 18 0931264.5 ft. MGO - General Observation - CAPPED LATERAL 9 O'CLOCK @ MH

Observation photos (3)

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    16.4 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    37.3 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    67.7 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P14780Work order 711900

Observations (24)

DistanceCodeObservation
67.7CM—
137.6TFC—
38.4TFC—
236.1TF—
159.5TS—
35.9TFC—
70.1RFL—
37.3FM—
264.5CM—
82.1RFJ—
185.3TFC—
83.9TF—
0MWL—
16.4CM—
0AMH18 0932
264.5AMH18 0931
86.8TFC—
233.6TF—
0MWM—
264.5MGOCAPPED LATERAL 9 O'CLOCK @ MH
188.2TFC—
134.8TFC—
70.1TS—
0MGOCONNECTION AT MH 9 O'CLOCK

Properties (6)

additional_info
SC359667
custom_field_two
3
customer
LACSD
datetime
2018-06-27T23:13:11-07:00
documentation
PROPIPE
is_lateral_inspection
false
