Wastewater/Activity/PacpInspection/1.0Dec 28, 2017, 08:41 AM
14 0209_14 0208 _12282017_004133.mp4
- Date
- 12/28/2017
- W/O
- 678026
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00584
- PipeID
- P18248
- Time
- 12:41 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5357
- Sewer Name
- 14 WEST SIDE TRUNK
- City
- LANCASTER
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 14
- Page No.
- 18
- Purpose
- Routine Assessment
- Project
- WO_678026_DISTRICT14_DEC2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 14 0209
- Downstream MH
- 14 0208
- Dir. of Survey
- Downstream
- Length Surveyed
- 229.1 ft.
- Total Length
- 229.1 ft.
- Structural Index
- 3
- Structural Quick
- 4C3C
- Structural Rating
- 147
- O&M Index
- 2
- O&M Quick
- 2H11
- O&M Rating
- 91
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 238
Observation photos (7)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
12.7 ft. - Crack Spiral, from 08 to 10 o'clock, within 8 inches of joint: YES
22.5 ft. - Roots Fine Joint, at 03 o'clock, within 8 inches of joint: YESR
22.5 ft. - Crack Spiral, from 02 to 04 o'clock, within 8 inches of joint: YES
26 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
128.8 ft. - Fracture Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
167 ft. - Water Level, 50 %of cross sectional area
Observations (21)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWM | — |
| 2 | DAGS | — |
| 77 | TFA | — |
| 12.7 | CS | — |
| 186.3 | TFA | — |
| 188.6 | TFA | — |
| 167 | MWL | — |
| 0 | AMH | 14 0209 |
| 22.5 | RFJ | — |
| 71 | TFA | — |
| 128.8 | FM | — |
| 0 | MWL | — |
| 129.7 | TFA | — |
| 0 | MGO | ACTIVE CONNECTION AT MH 3 O'CLOCK |
| 127.2 | TFA | — |
| 128.8 | CM | — |
| 229.1 | AMH | 14 0208 |
| 227.7 | FM | — |
| 22.5 | CS | — |
| 227.7 | DAGS | — |
| 26 | CM | — |
Properties (6)
- additional_info
- SC346434
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2017-12-28T00:41:15-08:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
