Wastewater/Activity/PacpInspection/1.0Apr 20, 2018, 07:24 AM
22 0497_22 0496 _20042018_003346.mp4
- Date
- 04/20/2018
- W/O
- 695664
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00800
- PipeID
- P16836
- Time
- 12:24 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K5573
- Sewer Name
- 22 COVINA CONNECTION EXTENSION TRUNK
- City
- COVINA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 31
- Purpose
- Routine Assessment
- Project
- WO_695664_TV22031_APR2018
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 10 in.
- Width
- 10 in.
- Upstream MH
- 22 0497
- Downstream MH
- 22 0496
- Dir. of Survey
- Downstream
- Length Surveyed
- 169.2 ft.
- Total Length
- 169.2 ft.
- Structural Index
- 3
- Structural Quick
- 4133
- Structural Rating
- 13
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 13
Observation photos (4)
2 ft. - Surface Aggregate Projecting, from 02 to 10 o'clock, within 8 inches of joint: YES, Start
78.1 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
96.4 ft. - Fracture Multiple, from 12 to 12 o'clock, within 8 inches of joint: YES
122.7 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
Observations (18)
| Distance | Code | Observation |
|---|---|---|
| 169.2 | AMH | 22 0496 |
| 157.4 | TFC | — |
| 160.3 | TFC | — |
| 109.5 | TFC | — |
| 0 | AMH | 22 0497 |
| 112.2 | TFC | — |
| 19.1 | TFC | — |
| 167 | SAP | — |
| 16.1 | TFC | — |
| 0 | MWL | — |
| 78.1 | CM | — |
| 64 | TFC | — |
| 169.2 | MGO | ACTIVE CONNECTION AT MH 3 O'CLOCK |
| 60.9 | TFC | — |
| 96.4 | FM | — |
| 122.7 | CM | — |
| 0 | MWM | — |
| 2 | SAP | — |
Properties (6)
- additional_info
- SC358532
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2018-04-20T00:24:04-07:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
