Wastewater/Activity/PacpInspection/1.0Oct 3, 2016, 08:53 AM
01 0688_01 0687_03102016_015330.mp4
- Date
- 10/03/2016
- W/O
- 591536
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00199
- PipeID
- P01397
- Time
- 1:53 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3597
- Sewer Name
- 01 CALIFORNIA AVENUE EXTENSION TRUNK
- City
- SOUTH GATE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 11
- Purpose
- Routine Assessment
- Project
- WO_591536_TV01117_SEP2016
- Sewer Type
- Siphon
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 39 in.
- Width
- 39 in.
- Upstream MH
- 01 0688
- Downstream MH
- 01 0687
- Dir. of Survey
- Downstream
- Length Surveyed
- 8.4 ft.
- Total Length
- 8.5 ft.
- Structural Index
- 4
- Structural Quick
- 5131
- Structural Rating
- 8
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (4)
3.1 ft. - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
3.2 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: NO, Start
8.4 ft. - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish
8.5 ft. - Survey Abandoned - DOWN LEG OF THE U/S SIPHON
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 8.5 | MSA | DOWN LEG OF THE U/S SIPHON |
| 8.4 | SRV | — |
| 0 | MWM | — |
| 0 | AMH | 01 0688 |
| 8.4 | SAP | — |
| 3.1 | SRV | — |
| 3.2 | SAP | — |
Properties (6)
- additional_info
- SC306192
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2016-10-03T01:53:22-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
