Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 21, 2020, 10:58 AM

  • 01 0630_01 0629_5212020_035951.mp4

Date
05/21/2020
W/O
0829299
Weather
Dry
Operator/Surveyor
U-115-06022630
Sewer ID
Z00212
PipeID
P01126
Time
3:58 AM
Certificate
U-115-06022630
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1426
Sewer Name
01 MOUNTAIN VIEW-BELLE VERNON TRUNK
City
HUNTINGTON PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
10
Purpose
Routine Assessment
Project
20200519VMR_MOUNTAIN_VIEW_BELLE_VERNON_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
01 0630
Downstream MH
01 0629
Dir. of Survey
Downstream
Length Surveyed
419.9 ft.
Total Length
419.9 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
2
O&M Quick
2300
O&M Rating
6
Overall Index
2
Overall Quick
—
Overall Rating
9
Pipe schematic from manhole 01 0630 to 01 0629
MH: 01 0630MH: 01 0629downstream0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 03:59 AM0 ft. MWL - Water Level, 20 %of cross sectional area1.6 ft. LFW - Lining Failure Wrinkled, from 09 to 03 o'clock, within 8 inches of joint: NO3.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 05 o'clock, , within 8 inches of joint: NO, Start3.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 07 to 08 o'clock, , within 8 inches of joint: NO, Start53.4 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"104 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"152.6 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"204.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 4"254.3 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"305.1 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"414 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, at 03 o'clock, , within 8 inches of joint: NO416 ft. TFA - Tap Factory Made Active, at 11 o'clock, -, within 8 inches of joint: NO, 4"417 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 05 o'clock, , within 8 inches of joint: NO, Finish417 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 07 to 08 o'clock, , within 8 inches of joint: NO, Finish419.9 ft. AMH - Downstream Manhole, Survey Ends - 04:20 AM

Observation photos (2)

  • Lining Failure Wrinkled, from 09 to 03 o'clock, within 8 inches of joint: NO

    1.6 ft. - Lining Failure Wrinkled, from 09 to 03 o'clock, within 8 inches of joint: NO

  • Deposits Attached Grease, 5 %of cross sectional area, at 03 o'clock, , within 8 inches of joint: NO

    414 ft. - Deposits Attached Grease, 5 %of cross sectional area, at 03 o'clock, , within 8 inches of joint: NO

All inspections of P01126Work order 0829299

Observations (17)

DistanceCodeObservation
1.6LFW—
0MWM—
3.5DAGS—
417DAGS—
417DAGS—
53.4TF—
416TFA—
0AMH03:59 AM
419.9AMH04:20 AM
0MWL—
104TF—
254.3TF—
3.5DAGS—
152.6TF—
305.1TF—
414DAGS—
204.1TFA—

Properties (5)

custom_field_two
4
customer
LACSD
datetime
2020-05-21T03:58:49-07:00
documentation
REVELES, OLIVER III, CASTILLO, SKINNER
is_lateral_inspection
false
