Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 21, 2020, 08:04 AM

  • 01 0633_01 0632_5212020_012225.mp4

Date
05/21/2020
W/O
0829299
Weather
Dry
Operator/Surveyor
U-115-06022630
Sewer ID
Z00212
PipeID
P01129
Time
1:04 AM
Certificate
U-115-06022630
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1425
Sewer Name
01 MOUNTAIN VIEW-BELLE VERNON TRUNK
City
HUNTINGTON PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
10
Purpose
Routine Assessment
Project
20200519VMR_MOUNTAIN_VIEW_BELLE_VERNON_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
01 0633
Downstream MH
01 0632
Dir. of Survey
Downstream
Length Surveyed
298.1 ft.
Total Length
298.1 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
3
Pipe schematic from manhole 01 0633 to 01 0632
MH: 01 0633MH: 01 0632downstream0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01:21 AM2.3 ft. LFW - Lining Failure Wrinkled, from 11 to 12 o'clock, within 8 inches of joint: NO35 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"93.8 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"146.7 ft. TFA - Tap Factory Made Active, at 11 o'clock, -, within 8 inches of joint: NO, 4"193.6 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"244.8 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"290.9 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4"296.6 ft. LFZ - Lining Failure Other, at 03 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT296.6 ft. LFZ - Lining Failure Other, at 09 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT298.1 ft. AMH - Downstream Manhole, Survey Ends - 01:40 AM

Observation photos (2)

  • Lining Failure Other, at 03 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT

    296.6 ft. - Lining Failure Other, at 03 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT

  • Lining Failure Other, at 09 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT

    296.6 ft. - Lining Failure Other, at 09 o'clock, within 8 inches of joint: NO - POSSIBLE CUTOUT

All inspections of P01129Work order 0829299

Observations (13)

DistanceCodeObservation
2.3LFW—
193.6TF—
93.8TF—
0MWL—
0MWM—
146.7TFA—
35TF—
0AMH01:21 AM
296.6LFZPOSSIBLE CUTOUT
298.1AMH01:40 AM
296.6LFZPOSSIBLE CUTOUT
244.8TF—
290.9TF—

Properties (5)

custom_field_two
4
customer
LACSD
datetime
2020-05-21T01:04:49-07:00
documentation
REVELES, OLIVER III, CASTILLO, SKINNER
is_lateral_inspection
false
