Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 19, 2020, 09:42 AM

  • 01 0651_01 0650_5192020_030225.mp4

Date
05/19/2020
W/O
0829299
Weather
Dry
Operator/Surveyor
U-115-06022630
Sewer ID
Z00212
PipeID
P01150
Time
2:42 AM
Certificate
U-115-06022630
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1422
Sewer Name
01 MOUNTAIN VIEW-BELLE VERNON TRUNK
City
HUNTINGTON PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
10
Purpose
Routine Assessment
Project
20200519VMR_MOUNTAIN_VIEW_BELLE_VERNON_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
01 0650
Downstream MH
01 0651
Dir. of Survey
Upstream
Length Surveyed
132.3 ft.
Total Length
132.3 ft.
Structural Index
3
Structural Quick
3200
Structural Rating
6
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
6
Pipe schematic from manhole 01 0650 to 01 0651
MH: 01 0650MH: 01 0651upstream0 ft. AMH - Upstream Manhole, Survey Ends - 03:18 am40.9 ft. LFW - Lining Failure Wrinkled, from 03 to 04 o'clock, within 8 inches of joint: NO, Finish49.7 ft. LFW - Lining Failure Wrinkled, from 09 to 10 o'clock, within 8 inches of joint: NO, Finish60.4 ft. LFZ - Lining Failure Other, from 12 to 05 o'clock, within 8 inches of joint: NO - thicker strip, seal60.8 ft. LFZ - Lining Failure Other, from 07 to 12 o'clock, within 8 inches of joint: NO - thicker strip74.2 ft. LFW - Lining Failure Wrinkled, from 09 to 10 o'clock, within 8 inches of joint: NO, Start87.7 ft. LFW - Lining Failure Wrinkled, from 03 to 04 o'clock, within 8 inches of joint: NO, Start90.9 ft. SZ - Surface Other, at 02 o'clock, within 8 inches of joint: YES - Patch132.3 ft. MWL - Water Level, 20 %of cross sectional area132.3 ft. MWM - Water Mark, 40 %of cross sectional area132.3 ft. TFA - Tap Factory Made Active, at 09 o'clock, -, within 8 inches of joint: NO, 4"132.3 ft. AMH - Downstream Manhole, Survey Begins - 03:00 AM

Observation photos (2)

  • Lining Failure Other, from 07 to 12 o'clock, within 8 inches of joint: NO - thicker strip

    71.5 ft. - Lining Failure Other, from 07 to 12 o'clock, within 8 inches of joint: NO - thicker strip

  • Lining Failure Other, from 12 to 05 o'clock, within 8 inches of joint: NO - thicker strip, seal

    71.9 ft. - Lining Failure Other, from 12 to 05 o'clock, within 8 inches of joint: NO - thicker strip, seal

All inspections of P01150Work order 0829299

Observations (12)

DistanceCodeObservation
0MWL—
44.6LFW—
41.4SZPatch
0MWM—
58.1LFW—
0TFA—
71.5LFZthicker strip
82.6LFW—
132.3AMH03:18 am
0AMH03:00 AM
91.4LFW—
71.9LFZthicker strip, seal

Properties (6)

custom_field_two
3
customer
LACSD
datetime
2020-05-19T02:42:17-07:00
documentation
REVELES, OLIVER III, CASTILLO, SKINNER
is_lateral_inspection
false
lining
CIPP
