Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 24, 2016, 04:29 PM

  • 16 0578_16 0577_8242016_100059.mp4

Date
08/24/2016
W/O
0585428
Weather
Dry
Operator/Surveyor
MIRANDA
Sewer ID
Z00659
PipeID
P13629
Time
9:29 AM
Certificate
U-1014-06022542
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7213
Sewer Name
16 LAMANDA PARK TRUNK
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
11
Purpose
Routine Assessment
Project
20160824AM_LAMANDA_PARK_TRUNK
Material
Reinforced Concrete Pipe
Shape
Circular
Height
16.90999984741211 in.
Upstream MH
16 0577
Downstream MH
16 0578
Dir. of Survey
Upstream
Length Surveyed
210.2 ft.
Total Length
210.2 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 16 0577 to 16 0578
MH: 16 0577MH: 16 0578upstream0 ft. AMH - Upstream Manhole, Survey Ends - 10:13 AM0.3 ft. MGO - General Observation - CORRODED CHANNEL0.7 ft. MGO - General Observation - ACTIVE CONN. INSIDE THE MH. @ 12 O'CLOCK0.7 ft. MGO - General Observation - ACTIVE CONN. INSIDE THE MH. @ 09 O'CLOCK0.9 ft. MGO - General Observation - SLIGHT GREASE THROUGHOUT THE REACH0.9 ft. MGO - General Observation - MAG COAT PEELING/FLAKING THROUGHOUT THE REACH93.2 ft. TF - Tap Factory Made, at 01 o'clock, -, within 8 inches of joint: NO, 4" - OPEN, UNSEALED162.3 ft. TF - Tap Factory Made, at 01 o'clock, -, within 8 inches of joint: NO, 4" - OPEN, UNSEALED184.5 ft. TFA - Tap Factory Made Active, at 01 o'clock, -, within 8 inches of joint: NO, 4" - UNSEALED187.2 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: NO, 4", 6" - OPEN, UNSEALED210.2 ft. MWL - Water Level, 5 %of cross sectional area210.2 ft. MWM - Water Mark, 10 %of cross sectional area210.2 ft. AMH - Downstream Manhole, Survey Begins - 10:00 AM

Observation photos (4)

  • Water Level, 5 %of cross sectional area

    0 ft. - Water Level, 5 %of cross sectional area

  • Downstream Manhole, Survey Begins - 10:00 AM

    0 ft. - Downstream Manhole, Survey Begins - 10:00 AM

  • Tap Factory Made Active, at 01 o'clock, -, within 8 inches of joint: NO, 4" - UNSEALED

    25.7 ft. - Tap Factory Made Active, at 01 o'clock, -, within 8 inches of joint: NO, 4" - UNSEALED

  • General Observation - CORRODED CHANNEL

    209.9 ft. - General Observation - CORRODED CHANNEL

All inspections of P13629Work order 0585428

Observations (13)

DistanceCodeObservation
209.5MGOACTIVE CONN. INSIDE THE MH. @ 12 O'CLOCK
209.3MGOSLIGHT GREASE THROUGHOUT THE REACH
0MWL—
0MWM—
25.7TFAUNSEALED
209.9MGOCORRODED CHANNEL
117TFOPEN, UNSEALED
0AMH10:00 AM
209.3MGOMAG COAT PEELING/FLAKING THROUGHOUT THE REACH
210.2AMH10:13 AM
209.5MGOACTIVE CONN. INSIDE THE MH. @ 09 O'CLOCK
23TFOPEN, UNSEALED
47.9TFOPEN, UNSEALED

Properties (8)

custom_field_three
PIPE IS LINED
custom_field_two
4
customer
LACSD
datetime
2016-08-24T09:29:58-07:00
documentation
MIRANDA, SHADLER, FRANKLIN
is_lateral_inspection
false
lining
CIPP
year_laid
20030423
