Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 21, 2016, 09:34 AM

  • C 0568_C 0567_11212016_015117.mp4

Date
11/21/2016
W/O
0602265
Weather
Heavy Rain
Operator/Surveyor
MARTIN
Sewer ID
Z00362
PipeID
P04752
Time
1:34 AM
Certificate
U-104-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0351
Sewer Name
C JOINT OUTFALL C - UNIT 4D
City
LAKEWOOD
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
08
Purpose
Capital Improvement Program Assesment
Project
20161121MDM_JOINT_OUTFALL_C_UNIT_4D
Material
Vitrified Clay Pipe
Shape
Circular
Height
27 in.
Upstream MH
C 0568
Downstream MH
C 0567
Dir. of Survey
Downstream
Length Surveyed
325.8 ft.
Total Length
325.8 ft.
Structural Index
3
Structural Quick
3724
Structural Rating
29
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
29
Pipe schematic from manhole C 0568 to C 0567
MH: C 0568MH: C 0567downstream0 ft. AMH - Upstream Manhole, Survey Begins - 1:50AM0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. MWM - Water Mark, 40 %of cross sectional area2 ft. MGO - General Observation - WHITE COATING OR BUILDUP ON PIPE6.9 ft. FC - Fracture Circumferential, from 12 to 01 o'clock, within 8 inches of joint: YES - HAIRLINE6.9 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SLIGHT11.4 ft. FS - Fracture Spiral, from 11 to 01 o'clock, within 8 inches of joint: YES - SLIGHT25.9 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - H25.9 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT87.9 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - SL88 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SLIGHT111 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - SLIGHT129.1 ft. FC - Fracture Circumferential, from 10 to 12 o'clock, within 8 inches of joint: YES - H176.2 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - SLIGHT196.6 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H229 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SL229 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish - H232.6 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES, Start - H296.6 ft. FL - Fracture Longitudinal, at 09 o'clock, within 8 inches of joint: YES, Finish - H325.8 ft. AMH - Downstream Manhole, Survey Ends - 2:25AM

Observation photos (6)

  • General Observation - WHITE COATING OR BUILDUP ON PIPE

    2 ft. - General Observation - WHITE COATING OR BUILDUP ON PIPE

  • Fracture Spiral, from 11 to 01 o'clock, within 8 inches of joint: YES - SLIGHT

    11.4 ft. - Fracture Spiral, from 11 to 01 o'clock, within 8 inches of joint: YES - SLIGHT

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT

    25.9 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - SLIGHT

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SLIGHT

    88 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SLIGHT

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

    196.6 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start - H

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SL

    229 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - SL

All inspections of P04752Work order 0602265

Observations (20)

DistanceCodeObservation
11.4FSSLIGHT
111FCSLIGHT
229FLSL
0AMH1:50AM
196.6FLH
87.9FCSL
232.6FLH
296.6FLH
176.2FLSLIGHT
6.9FCHAIRLINE
229FLH
0MWL—
325.8AMH2:25AM
88FLSLIGHT
2MGOWHITE COATING OR BUILDUP ON PIPE
129.1FCH
25.9FLH
6.9FLSLIGHT
0MWM—
25.9FLSLIGHT

Properties (6)

custom_field_three
LONG SLIGHTS JOINT TO JOINT LONGER
custom_field_two
2
customer
LACSD
datetime
2016-11-21T01:34:40-08:00
documentation
MARTIN,MANANES,REVELES
is_lateral_inspection
false
