Wastewater/Activity/PacpInspection/1.0Jul 28, 2016, 08:20 AM
19 0270_19 0269_7282016_012810.mp4
- Date
- 07/28/2016
- W/O
- 0579970
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00733
- PipeID
- P15240
- Time
- 1:20 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H0209
- Sewer Name
- 19 219TH STREET TRUNK
- City
- HAWAIIAN GARDENS
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 19
- Page No.
- 06
- Purpose
- Routine Assessment
- Project
- 20160727MDM_219TH_STREET_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 12 in.
- Upstream MH
- 19 0270
- Downstream MH
- 19 0269
- Dir. of Survey
- Downstream
- Length Surveyed
- 293.6 ft.
- Total Length
- 293.6 ft.
- Structural Index
- 3
- Structural Quick
- 3221
- Structural Rating
- 8
- O&M Index
- 4
- O&M Quick
- 5242
- O&M Rating
- 20
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 28
Observation photos (5)
0 ft. - Water Level, 70 %of cross sectional area
68 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 02 to 03 o'clock, , within 8 inches of joint: YES
202.4 ft. - Water Mark, 30 %of cross sectional area
218.9 ft. - Water Mark, 20 %of cross sectional area
240.2 ft. - Water Mark, 10 %of cross sectional area
Observations (28)
| Distance | Code | Observation |
|---|---|---|
| 240.2 | MWM | — |
| 163.3 | MWM | — |
| 218.9 | MWM | — |
| 121.4 | MWL | — |
| 0 | MWL | — |
| 293.2 | MGO | Conn. @ Mh, 9 O' Clock. Active |
| 163.3 | MWL | — |
| 184.8 | TB | Open |
| 218.4 | TB | Open |
| 293.6 | AMH | 2:05AM |
| 68 | DAE | — |
| 293.2 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 0 | MGO | Conn. @ Mh, 3 O' Clock. Active |
| 0 | MGO | Conn. @ Mh, 9 O' Clock. Active |
| 202.4 | MWL | — |
| 35.3 | MWL | — |
| 0 | AMH | 1:20AM |
| 158.7 | MWL | — |
| 218.2 | FL | HAIRLINE |
| 218.9 | FL | HAIRLINE |
| 202.4 | MWM | — |
| 218.9 | MWL | — |
| 240.2 | MWL | — |
| 0 | MWM | — |
| 35.3 | MWM | — |
| 0 | MGO | Conn. @ Mh, 6 O' Clock. Active |
| 68.8 | FC | HAIRLINE |
| 121.4 | MWM | — |
Properties (6)
- custom_field_three
- FEW HAIRLINES
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-07-28T01:20:00-07:00
- documentation
- MARTIN,MANANES,REVELES,OLIVER 111
- is_lateral_inspection
- false
