Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 23, 2016, 10:39 AM

  • 05 0186_05 0185_23112016_023952.mp4

Date
11/23/2016
W/O
602594
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00431
PipeID
P05478
Time
2:39 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3833
Sewer Name
05 DISTRICT #5 MAIN TRUNK
City
INGLEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
06
Purpose
Routine Assessment
Project
WO_602594_TV05228_NOV2016
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
15 in.
Upstream MH
05 0185
Downstream MH
05 0186
Dir. of Survey
Upstream
Length Surveyed
277.5 ft.
Total Length
277.5 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
3
O&M Quick
3411
O&M Rating
13
Overall Index
3
Overall Quick
—
Overall Rating
13
Pipe schematic from manhole 05 0185 to 05 0186
MH: 05 0185MH: 05 0186upstream0 ft. RMC - Roots Medium Connection, from 02 to 04 o'clock, 30 %, within 8 inches of joint: NO0 ft. MSA - Survey Abandoned - CAM BLKD BY ROOTS0 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"15 ft. RMC - Roots Medium Connection, from 08 to 10 o'clock, 20 %, within 8 inches of joint: NO15 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: NO, 6"50.5 ft. RMC - Roots Medium Connection, from 08 to 10 o'clock, 15 %, within 8 inches of joint: NO50.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"52.6 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"66.7 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"107.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"134.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"141.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"183.5 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"185.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"199.2 ft. RMC - Roots Medium Connection, from 02 to 04 o'clock, 15 %, within 8 inches of joint: NO199.2 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"227.1 ft. RFL - Roots Fine Lateral, at 10 o'clock227.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"261.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6"264.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6"277.5 ft. MWM - Water Mark, 10 %of cross sectional area277.5 ft. MGO - Reversal Inspection277.5 ft. AMH - Downstream Manhole, Survey Begins - 05 0185277.5 ft. MWL - Water Level, 10 %of cross sectional area

Observation photos (3)

  • Roots Fine Lateral, at 10 o'clock

    50.4 ft. - Roots Fine Lateral, at 10 o'clock

  • Roots Medium Connection, from 02 to 04 o'clock, 15 %, within 8 inches of joint: NO

    78.3 ft. - Roots Medium Connection, from 02 to 04 o'clock, 15 %, within 8 inches of joint: NO

  • Roots Medium Connection, from 02 to 04 o'clock, 30 %, within 8 inches of joint: NO

    277.5 ft. - Roots Medium Connection, from 02 to 04 o'clock, 30 %, within 8 inches of joint: NO

All inspections of P05478Work order 602594

Observations (24)

DistanceCodeObservation
78.3RMC—
262.5RMC—
50.4RFL—
0MWM—
142.6TF—
224.9TF—
0MGO—
0AMH05 0185
210.8TF—
277.5RMC—
16.2TF—
0MWL—
13.2TF—
170.3TF—
136.3TF—
227RMC—
91.9TF—
78.3TF—
227TF—
262.5TB—
277.5MSACAM BLKD BY ROOTS
50.4TF—
94TF—
277.5TF—

Properties (6)

additional_info
SC304583
custom_field_two
5
customer
LACSD
datetime
2016-11-23T02:39:01-08:00
documentation
PROPIPE
is_lateral_inspection
false
