Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 4, 2016, 07:34 AM

  • 01 0675_01 0674B_04102016_003507.mp4

Date
10/04/2016
W/O
591536
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00199
PipeID
P01384
Time
12:34 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3598
Sewer Name
01 CALIFORNIA AVENUE EXTENSION TRUNK
City
SOUTH GATE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
14
Purpose
Routine Assessment
Project
WO_591536_TV01117_SEP2016
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
01 0675
Downstream MH
01 0674B
Dir. of Survey
Downstream
Length Surveyed
46.5 ft.
Total Length
46.6 ft.
Structural Index
3
Structural Quick
3800
Structural Rating
24
O&M Index
2
O&M Quick
2700
O&M Rating
14
Overall Index
3
Overall Quick
—
Overall Rating
38
Pipe schematic from manhole 01 0675 to 01 0674B
MH: 01 0675MH: 01 0674Bdownstream0 ft. MGO - General Observation - CONNECTION AT MH 9 O'CLOCK0 ft. MGO - General Observation - PIPE IS NOT 24" UNKNOWN PIPE SIZE0 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK0 ft. AMH - Upstream Manhole, Survey Begins - 01 06750 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MWL - Water Level, 20 %of cross sectional area7 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start7 ft. DSZ - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start43 ft. DSZ - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Finish45.8 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish46.6 ft. AMH - Downstream Manhole, Survey Ends - 01 0674B

Observation photos (3)

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    7 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start

    7 ft. - Deposits Settled Other, 10 %of cross sectional area, at 06 o'clock, , within 8 inches of joint: NO, Start

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

    45.8 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

All inspections of P01384Work order 591536

Observations (11)

DistanceCodeObservation
0MGOCONNECTION AT MH 9 O'CLOCK
45.8SAP—
0MGOPIPE IS NOT 24" UNKNOWN PIPE SIZE
0MGOCONNECTION AT MH 3 O'CLOCK
7SAP—
0AMH01 0675
43DSZ—
0MWM—
46.6AMH01 0674B
0MWL—
7DSZ—

Properties (6)

additional_info
SC306193
custom_field_two
3
customer
LACSD
datetime
2016-10-04T00:34:49-07:00
documentation
PROPIPE
is_lateral_inspection
false
