Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 29, 2018, 05:58 PM

  • Section#2_15 0437_B JOINT__1292018__G6738.mp4

Date
01/29/2018
W/O
0630292
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00625
PipeID
P20100
Time
9:58 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G6738
Sewer Name
15 RIVER AVENUE TRUNK
City
ROSEMEAD
Loc. details
Other
Location Code
Z
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
27
Purpose
Routine Assessment
Project
20180129DF_RIVER_AVE_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Upstream MH
15 0437
Downstream MH
B JOINT
Dir. of Survey
Downstream
Length Surveyed
49.7 ft.
Total Length
49.7 ft.
Structural Index
2
Structural Quick
2A11
Structural Rating
23
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
23
Pipe schematic from manhole 15 0437 to B JOINT
MH: 15 0437MH: B JOINTdownstream0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 11:07 AM2 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start28.4 ft. MGP - General Photograph - DEBRIS/GREWASE43 ft. CS - Crack Spiral, from 07 to 04 o'clock, within 8 inches of joint: YES48.6 ft. JOM - Joint Offset Medium - .5"49.7 ft. AMH - Downstream Manhole, Survey Ends - 11:16 AM49.7 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

Observation photos (3)

  • General Photograph - DEBRIS/GREWASE

    28.4 ft. - General Photograph - DEBRIS/GREWASE

  • Crack Spiral, from 07 to 04 o'clock, within 8 inches of joint: YES

    43 ft. - Crack Spiral, from 07 to 04 o'clock, within 8 inches of joint: YES

  • Joint Offset Medium - .5"

    48.6 ft. - Joint Offset Medium - .5"

All inspections of P20100Work order 0630292

Observations (9)

DistanceCodeObservation
49.7AMH11:16 AM
28.4MGPDEBRIS/GREWASE
49.7SSS—
48.6JOM.5"
0MWL—
2SSS—
43CS—
0MWM—
0AMH11:07 AM

Properties (5)

custom_field_two
3
customer
LACSD
datetime
2018-01-29T09:58:18-08:00
documentation
FRANKLIN, IGNACIO, VENDRYES
is_lateral_inspection
false
