Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 15, 2019, 08:39 AM

  • 18 0974_18 0973_11152019_004836.mp4

Date
11/15/2019
W/O
0798462
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00716
PipeID
P14826
Time
12:39 AM
Certificate
1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1310
Sewer Name
18 WORSHAM CREEK TRUNK
City
WHITTIER
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
11
Purpose
Routine Assessment
Project
20191114MDM_WORSHAM_CREEK_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Upstream MH
18 0974
Downstream MH
18 0973
Dir. of Survey
Downstream
Length Surveyed
201.2 ft.
Total Length
201.2 ft.
Structural Index
4
Structural Quick
4100
Structural Rating
4
O&M Index
4
O&M Quick
4131
O&M Rating
7
Overall Index
4
Overall Quick
—
Overall Rating
11
Pipe schematic from manhole 18 0974 to 18 0973
MH: 18 0974MH: 18 0973downstream0 ft. MGO - General Observation - MH CONN 9:00 OPEN0 ft. AMH - Upstream Manhole, Survey Begins - 12:35AM0 ft. MWL - Water Level, 0 %of cross sectional area - DRY LINE0 ft. MWM - Water Mark, 20 %of cross sectional area8 ft. MGO - General Observation - 8" VCP-PVCP109.4 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open123 ft. MWL - Water Level, 90 %of cross sectional area123 ft. MWLS - Water Level, Sag in pipe, 90 %of cross sectional area, Start135.3 ft. MCU - Camera Underwater135.3 ft. DSZ - Deposits Settled Other, 20 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: NO - SLUDGE168.9 ft. MGO - General Observation - CAMERA ABOVE WATER172.4 ft. MWLS - Water Level, Sag in pipe, 90 %of cross sectional area, Finish184.5 ft. MWL - Water Level, 0 %of cross sectional area201.2 ft. MSA - Survey Abandoned - TOP WRINGLES IN LINER CAMERA WILL NOT FIT

Observation photos (3)

  • General Observation - 8" VCP-PVCP

    8 ft. - General Observation - 8" VCP-PVCP

  • Water Level, Sag in pipe, 90 %of cross sectional area, Start

    123 ft. - Water Level, Sag in pipe, 90 %of cross sectional area, Start

  • Survey Abandoned - TOP WRINGLES IN LINER CAMERA WILL NOT FIT

    201.2 ft. - Survey Abandoned - TOP WRINGLES IN LINER CAMERA WILL NOT FIT

All inspections of P14826Work order 0798462

Observations (14)

DistanceCodeObservation
184.5MWL—
123MWL—
135.3MCU—
123MWLS—
135.3DSZSLUDGE
8MGO8" VCP-PVCP
0MGOMH CONN 9:00 OPEN
201.2MSATOP WRINGLES IN LINER CAMERA WILL NOT FIT
168.9MGOCAMERA ABOVE WATER
172.4MWLS—
0AMH12:35AM
109.4TBOpen
0MWLDRY LINE
0MWM—

Properties (7)

custom_field_three
LINER GOOD COND
custom_field_two
4
customer
LACSD
datetime
2019-11-15T00:39:13-08:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
lining
PVCP
