Wastewater/Activity/PacpInspection/1.0Oct 23, 2019, 08:28 AM
16 0590_16 0747_10232019_005036.mp4
- Date
- 10/23/2019
- W/O
- 792814
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00664
- PipeID
- P22995
- Time
- 1:28 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K7051
- Sewer Name
- 16 PASADENA EAST-WEST INTERCEPTOR TRUNK
- City
- PASADENA
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 10
- Purpose
- Routine Assessment
- Project
- WO_792814_TV16030_OCT2019
- Sewer Type
- Gravity
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 33 in.
- Width
- 33 in.
- Upstream MH
- 16 0590
- Downstream MH
- 16 0747
- Dir. of Survey
- Downstream
- Length Surveyed
- 493.5 ft.
- Total Length
- 493.5 ft.
- Structural Index
- 3
- Structural Quick
- 3S2F
- Structural Rating
- 362
- O&M Index
- 2
- O&M Quick
- 2S00
- O&M Rating
- 196
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 558
Observation photos (2)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
321.7 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 2 | DAGS | — |
| 2 | SZ | 50% MAG |
| 0 | AMH | 16 0590 |
| 493.5 | AMH | 16 0747 |
| 492.8 | SSS | — |
| 0 | MWM | — |
| 483.6 | TBA | OPEN |
| 492.8 | SAP | — |
| 2 | MGO | ROACHES THROUGHOUT THE REACH |
| 491 | SZ | 75% MAG |
| 0 | MWL | — |
| 492.8 | DAGS | — |
| 2 | SAP | — |
| 321.7 | SSS | — |
Properties (6)
- additional_info
- SC378720
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2019-10-23T01:28:31-07:00
- documentation
- PRO PIPE
- is_lateral_inspection
- false
