Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 22, 2019, 05:03 AM

  • 16 0605_16 0604 _10212019_210304.mp4

Date
10/21/2019
W/O
792814
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00664
PipeID
P13655
Time
10:03 PM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K7050
Sewer Name
16 PASADENA EAST-WEST INTERCEPTOR TRUNK
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 16
Page No.
10
Purpose
Routine Assessment
Project
WO_792814_TV16030_OCT2019
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
39 in.
Width
39 in.
Upstream MH
16 0605
Downstream MH
16 0604
Dir. of Survey
Downstream
Length Surveyed
414.5 ft.
Total Length
414.5 ft.
Structural Index
3
Structural Quick
3O2O
Structural Rating
410
O&M Index
2
O&M Quick
2P00
O&M Rating
166
Overall Index
2
Overall Quick
—
Overall Rating
576
Pipe schematic from manhole 16 0605 to 16 0604
MH: 16 0605MH: 16 0604downstream0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. MGO - General Observation - COCKROACHES IN MANHOLE0 ft. AMH - Upstream Manhole, Survey Begins - 16 06050 ft. MGO - General Observation - CONN @ MH 9 O'CLOCK/ACTIVE0 ft. MWL - Water Level, 15 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start2 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start2 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Start - 70% MAG5.5 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start144.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"192.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"233.8 ft. TBA - Tap Break-In Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"281 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"297.1 ft. TBA - Tap Break-In Active, at 11 o'clock, -, within 8 inches of joint: NO, 6"375 ft. TBA - Tap Break-In Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"413 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish413 ft. SZ - Surface Other, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish - 70% MAG414 ft. MGO - General Observation - POSSIBLE AIRLINE/DROP CONN 12 O'CLOCK414.5 ft. SAP - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish414.5 ft. AMH - Downstream Manhole, Survey Ends - 16 0604414.5 ft. MGO - General Observation - CONN @ MH 9 O'CLOCK/ACTIVE414.5 ft. MGO - General Observation - COCKROACHES IN MANHOLE414.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish

Observation photos (4)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

    5.5 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start

  • General Observation - COCKROACHES IN MANHOLE

    414.5 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P13655Work order 792814

Observations (23)

DistanceCodeObservation
0MWM—
0MGOCOCKROACHES IN MANHOLE
2DAGS—
2SSS—
414.5SAP—
375TBA—
414.5AMH16 0604
233.8TBA—
413SSS—
414.5MGOCONN @ MH 9 O'CLOCK/ACTIVE
413SZ70% MAG
144.4TFC—
192.6TFC—
0AMH16 0605
281TFC—
414MGOPOSSIBLE AIRLINE/DROP CONN 12 O'CLOCK
414.5MGOCOCKROACHES IN MANHOLE
5.5SAP—
0MGOCONN @ MH 9 O'CLOCK/ACTIVE
414.5DAGS—
0MWL—
297.1TBA—
2SZ70% MAG

Properties (6)

additional_info
SC378719
custom_field_two
2
customer
LACSD
datetime
2019-10-21T22:03:37-07:00
documentation
PRO PIPE
is_lateral_inspection
false
