Wastewater/Activity/PacpInspection/1.0Nov 6, 2019, 08:43 AM
15 0783_15 0781_1162019_005330.mp4
- Date
- 11/06/2019
- W/O
- 0793083
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00593
- PipeID
- P12983
- Time
- 12:43 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1300R
- Sewer Name
- 15 ARCADIA-SIERRA MADRE TRUNK, SECTS 2&5
- City
- PASADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 04
- Purpose
- Maintenance Related
- Project
- 20191106MDM_ARACIA_SIERRA_MADRE_TRUNK_SECTS_2_5
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Upstream MH
- 15 0781
- Downstream MH
- 15 0783
- Dir. of Survey
- Upstream
- Length Surveyed
- 265.8 ft.
- Total Length
- 265.8 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 3122
- O&M Rating
- 8
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (2)
2 ft. - Deposits Attached Grease, 4 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
221.5 ft. - Roots Medium Connection, from 07 to 11 o'clock, 15 %, within 8 inches of joint: YES
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 36.7 | TF | Open |
| 0 | AMH | 12:45AM |
| 85.8 | TFC | Capped |
| 265.2 | MGO | MH CONN 3:00 ACTIVE |
| 0 | MWL | — |
| 152.9 | TFC | Capped |
| 221.5 | TFD | Open-95% ROOTS |
| 221.5 | RMC | — |
| 2 | DAGS | — |
| 0 | MWM | — |
| 265.8 | AMH | 1:00AM |
| 265.2 | DAGS | — |
| 7.5 | RFJ | 3% |
Properties (5)
- additional_info
- POST ROOT EVALUATION ONLY
- customer
- LACSD
- datetime
- 2019-11-06T00:43:35-08:00
- documentation
- MARTIN,OLIVER 111,CASTILLO
- is_lateral_inspection
- false
