Wastewater/Activity/PacpInspection/1.0Nov 2, 2019, 11:57 AM
03 0288_02 0287_1122019_050520.mp4
- Date
- 11/02/2019
- W/O
- 0792616
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00359
- PipeID
- P23026
- Time
- 4:57 AM
- Certificate
- U-1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1296
- Sewer Name
- 03 ANAHEIM STREET TRUNK
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 23
- Purpose
- Routine Assessment
- Project
- 20191102MDM_ANAHEIM_STREET_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 36 in.
- Upstream MH
- 03 0288
- Downstream MH
- 02 0287
- Dir. of Survey
- Downstream
- Length Surveyed
- 138.3 ft.
- Total Length
- 138.3 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 0
- Overall Quick
- —
- Overall Rating
- 0
Observation photos (4)
0 ft. - Upstream Manhole, Survey Begins(NO MH OPENING IN LINER) - 5:05AM
8.2 ft. - General Observation - 36" VCP-FR-POLY LINER
8.7 ft. - General Observation - BULID-UP ON LINER
98.6 ft. - General Photograph
Observations (7)
| Distance | Code | Observation |
|---|---|---|
| 8.7 | MGO | BULID-UP ON LINER |
| 98.6 | MGP | — |
| 0 | MWL | — |
| 138.3 | AMH | 5:15AM |
| 0 | MWM | — |
| 0 | AMH | 5:05AM |
| 8.2 | MGO | 36" VCP-FR-POLY LINER |
Properties (7)
- custom_field_three
- LINER GOOD COND
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2019-11-02T04:57:47-07:00
- documentation
- MARTIN,REVELES,OLIVER 111,CASTILLO
- is_lateral_inspection
- false
- lining
- FR POLY LINE
