Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 2, 2019, 10:13 AM

  • 03 0613_03 0288_1122019_043224.mp4

Date
11/02/2019
W/O
0792616
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00359
PipeID
P23026
Time
3:13 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1296
Sewer Name
03 ANAHEIM STREET TRUNK
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
23
Purpose
Routine Assessment
Project
20191102MDM_ANAHEIM_STREET_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
36 in.
Upstream MH
03 0613
Downstream MH
03 0288
Dir. of Survey
Downstream
Length Surveyed
355.1 ft.
Total Length
355.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 03 0613 to 03 0288
MH: 03 0613MH: 03 0288downstream0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 4:30AM18.9 ft. MGO - General Observation - WHITE BUILD-UP ON LINER37.4 ft. MGO - General Observation - BUILD-UP PEELING OR COATING56 ft. MGO - General Observation - 36: VCP-FR-POLY LINE142.9 ft. MGO - General Observation - LINER WITH NO BUILD-UP355.1 ft. AMH - Downstream Manhole, Survey Ends( NO MH OPENING IN LINER) - 4:55AM

Observation photos (5)

  • General Observation - WHITE BUILD-UP ON LINER

    18.9 ft. - General Observation - WHITE BUILD-UP ON LINER

  • General Observation - BUILD-UP PEELING OR COATING

    37.4 ft. - General Observation - BUILD-UP PEELING OR COATING

  • General Observation - 36: VCP-FR-POLY LINE

    56 ft. - General Observation - 36: VCP-FR-POLY LINE

  • General Observation - LINER WITH NO BUILD-UP

    142.9 ft. - General Observation - LINER WITH NO BUILD-UP

  • Downstream Manhole, Survey Ends( NO MH OPENING IN LINER) - 4:55AM

    355.1 ft. - Downstream Manhole, Survey Ends( NO MH OPENING IN LINER) - 4:55AM

All inspections of P23026Work order 0792616

Observations (8)

DistanceCodeObservation
0MWM—
142.9MGOLINER WITH NO BUILD-UP
0MWL—
37.4MGOBUILD-UP PEELING OR COATING
0AMH4:30AM
56MGO36: VCP-FR-POLY LINE
18.9MGOWHITE BUILD-UP ON LINER
355.1AMH4:55AM

Properties (7)

custom_field_three
LINER GOOD COND
custom_field_two
4
customer
LACSD
datetime
2019-11-02T03:13:26-07:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
lining
FR POLY LINE
