Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 1, 2019, 07:20 AM

  • 19 0074_C 0376_1112019_003316.mp4

Date
11/01/2019
W/O
0800648
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00724
PipeID
P15106
Time
12:20 AM
Certificate
1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1295
Sewer Name
19 ELAINE AVENUE TRUNK
City
HAWAIIAN GARDENS
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
06
Purpose
Maintenance Related
Project
20191101_ELAINE_AVENUE_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
19 0074
Downstream MH
C 0376
Dir. of Survey
Downstream
Length Surveyed
308.8 ft.
Total Length
308.8 ft.
Structural Index
2
Structural Quick
2100
Structural Rating
2
O&M Index
5
O&M Quick
5141
O&M Rating
9
Overall Index
4
Overall Quick
—
Overall Rating
11
Pipe schematic from manhole 19 0074 to C 0376
MH: 19 0074MH: C 0376downstream0 ft. AMH - Upstream Manhole, Survey Begins - 12:25AM0 ft. MWL - Water Level, 60 %of cross sectional area0 ft. MWM - Water Mark, 40 %of cross sectional area5 ft. JOL - Joint Offset Large7 ft. MWL - Water Level, 70 %of cross sectional area7 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open14.1 ft. MWM - Water Mark, 40 %of cross sectional area14.1 ft. MWL - Water Level, 20 %of cross sectional area76.4 ft. MWL - Water Level, 70 %of cross sectional area76.4 ft. MWM - Water Mark, 80 %of cross sectional area102.7 ft. MWL - Water Level, 10 %of cross sectional area102.7 ft. MWM - Water Mark, 30 %of cross sectional area149.7 ft. MWL - Water Level, 40 %of cross sectional area230.6 ft. MWL - Water Level, 40 %of cross sectional area230.6 ft. MWM - Water Mark, 60 %of cross sectional area308 ft. MGO - General Observation - RECHECKED BOTTOM OF PIPE ON PULL BACK308 ft. MGO - General Observation - CHECKED TWO MANHOLES DOWNSTREAM NO GARDEN HOSE VISIBLE308.8 ft. AMH - Downstream Manhole, Survey Ends - 1:15AM

Observation photos (3)

  • Joint Offset Large

    5 ft. - Joint Offset Large

  • Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open

    7 ft. - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open

  • Downstream Manhole, Survey Ends - 1:15AM

    308.8 ft. - Downstream Manhole, Survey Ends - 1:15AM

All inspections of P15106Work order 0800648

Observations (18)

DistanceCodeObservation
76.4MWL—
5JOL—
308MGORECHECKED BOTTOM OF PIPE ON PULL BACK
230.6MWL—
0AMH12:25AM
230.6MWM—
308MGOCHECKED TWO MANHOLES DOWNSTREAM NO GARDEN HOSE VISIBLE
102.7MWL—
76.4MWM—
0MWL—
14.1MWM—
14.1MWL—
149.7MWL—
7MWL—
7TBOpen
102.7MWM—
308.8AMH1:15AM
0MWM—

Properties (5)

additional_info
GARDEN HOSE ATBREAK-IN CONN
customer
LACSD
datetime
2019-11-01T00:20:44-07:00
documentation
MARTIN,REVELES,CASTILLO
is_lateral_inspection
false
