Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 4, 2019, 12:06 PM

  • 15 0816_15 0815_1142019_041630.mp4

Date
11/04/2019
W/O
073082
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00593
PipeID
P13017
Time
4:06 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1298R
Sewer Name
15 ARCADIA-SIERRA MADRE TRUNK, SECTS 2&5
City
SIERRA MADRE
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
01
Purpose
Maintenance Related
Project
20191030MDM_ARCADIA_SIERRA_MADRE_TRUNK_SECTS_2_5
Material
NRCP
Shape
Circular
Height
9.420000076293945 in.
Upstream MH
15 0816
Downstream MH
15 0815
Dir. of Survey
Downstream
Length Surveyed
364.6 ft.
Total Length
364.6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
3
O&M Quick
3500
O&M Rating
15
Overall Index
3
Overall Quick
—
Overall Rating
15
Pipe schematic from manhole 15 0816 to 15 0815
MH: 15 0816MH: 15 0815downstream0 ft. AMH - Upstream Manhole, Survey Begins - 4:15AM0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. MGO - General Observation - MH CONN 3:00 ACTIVE0 ft. MGO - General Observation - MH CONN 9:00 OPEN44.3 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open48.6 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Open74.1 ft. TBD - Tap Break-In Defective, at 11 o'clock, -, , within 8 inches of joint: YES, 6" - Open-50% ROOTS74.1 ft. RMC - Roots Medium Connection, from 08 to 11 o'clock, 10 %, within 8 inches of joint: NO153.9 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open230.3 ft. TBD - Tap Break-In Defective, at 11 o'clock, -, , within 8 inches of joint: YES, 6" - Open-20% ROOTS230.3 ft. RMC - Roots Medium Connection, from 08 to 11 o'clock, 5 %, within 8 inches of joint: NO233.2 ft. TBD - Tap Break-In Defective, at 01 o'clock, -, , within 8 inches of joint: YES, 6" - Open-50% ROOTS364.1 ft. MGO - General Observation - MH CONN 9:00 STUB364.1 ft. MGO - General Observation - MH CONN 3:00 STUB364.6 ft. AMH - Downstream Manhole, Survey Ends - 4:40AM

Observation photos (2)

  • Roots Medium Connection, from 08 to 11 o'clock, 10 %, within 8 inches of joint: NO

    74.1 ft. - Roots Medium Connection, from 08 to 11 o'clock, 10 %, within 8 inches of joint: NO

  • Roots Medium Connection, from 08 to 11 o'clock, 5 %, within 8 inches of joint: NO

    230.3 ft. - Roots Medium Connection, from 08 to 11 o'clock, 5 %, within 8 inches of joint: NO

All inspections of P13017Work order 073082

Observations (16)

DistanceCodeObservation
364.1MGOMH CONN 9:00 STUB
0AMH4:15AM
230.3TBDOpen-20% ROOTS
0MWM—
364.1MGOMH CONN 3:00 STUB
230.3RMC—
74.1TBDOpen-50% ROOTS
364.6AMH4:40AM
153.9TBOpen
44.3TBOpen
0MWL—
74.1RMC—
0MGOMH CONN 3:00 ACTIVE
233.2TBDOpen-50% ROOTS
48.6TBOpen
0MGOMH CONN 9:00 OPEN

Properties (6)

additional_info
POST ROOT EVALUATION ONLY
customer
LACSD
datetime
2019-11-04T04:06:28-08:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
lining
CIPP
