Wastewater/Activity/PacpInspection/1.0Oct 28, 2019, 07:23 AM
15 0061_15 1044_10282019_005940.mp4
- Date
- 10/28/2019
- W/O
- 0799619
- Weather
- Dry
- Operator/Surveyor
- MARTIN
- Sewer ID
- Z00622
- PipeID
- P21479
- Time
- 12:23 AM
- Certificate
- 1014-06022543
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- H1288
- Sewer Name
- 15 PUENTE TRUNK
- City
- INDUSTRY
- Loc. details
- Easement/Right of Way
- Location Code
- D
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 35
- Purpose
- Maintenance Related
- Project
- 20191028MDM_PUENTE_TRUNK
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 10 in.
- Upstream MH
- 15 0061
- Downstream MH
- 15 1044
- Dir. of Survey
- Downstream
- Length Surveyed
- 5.5 ft.
- Total Length
- 5.5 ft.
- Structural Index
- 3
- Structural Quick
- 5131
- Structural Rating
- 12
- O&M Index
- 5
- O&M Quick
- 5100
- O&M Rating
- 5
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 17
Observation photos (5)
5 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES - MEDIUM
5 ft. - Joint Offset Large - 30% OFFSET SOIL VISIBLE
5 ft. - Joint Offset Large - SOIL VISIBLE
5 ft. - Broken Void Visible, from 10 to 02 o'clock, within 8 inches of joint: YES - AT OFFSET JOINT
5.5 ft. - Survey Abandoned - BROKEN PIPE LARGE OFFSET JOINT
Observations (8)
| Distance | Code | Observation |
|---|---|---|
| 5 | FL | MEDIUM |
| 0 | MWM | — |
| 5 | JOL | 30% OFFSET SOIL VISIBLE |
| 5.5 | MSA | BROKEN PIPE LARGE OFFSET JOINT |
| 5 | JOL | SOIL VISIBLE |
| 0 | MWL | — |
| 5 | BVV | AT OFFSET JOINT |
| 0 | AMH | 12:40AM |
Properties (5)
- additional_info
- LOOKING FOR PIPE DAMAGE
- customer
- LACSD
- datetime
- 2019-10-28T00:23:34-07:00
- documentation
- MARTIN,OLIVER 111,CASTILLO
- is_lateral_inspection
- false
