Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 30, 2019, 09:25 AM

  • 17 0009_17 0008_10302019_023607.mp4

Date
10/30/2019
W/O
0793144
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00668
PipeID
P13734
Time
2:25 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1289R
Sewer Name
17 DISTRICT #17 MAIN TRUNK
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 17
Page No.
07
Purpose
Maintenance Related
Project
20191028MDM_DISTRICT_17_MAIN_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
17 0009
Downstream MH
17 0008
Dir. of Survey
Downstream
Length Surveyed
377.5 ft.
Total Length
377.5 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
3523
O&M Rating
24
Overall Index
2
Overall Quick
—
Overall Rating
24
Pipe schematic from manhole 17 0009 to 17 0008
MH: 17 0009MH: 17 0008downstream0 ft. AMH - Upstream Manhole, Survey Begins - 2:25AM0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. MWL - Water Level, 15 %of cross sectional area153.7 ft. TFD - Tap Factory Made Defective, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Active-50% ROOTS153.7 ft. RML - Roots Medium Lateral, from 10 to 11 o'clock, 5 %, within 8 inches of joint: YES163.9 ft. RFJ - Roots Fine Joint, from 08 to 11 o'clock, within 8 inches of joint: YESR - 4%171.9 ft. RMJ - Roots Medium Joint, from 12 to 04 o'clock, 5 %, within 8 inches of joint: YESR184.3 ft. RFJ - Roots Fine Joint, from 01 to 04 o'clock, within 8 inches of joint: YESR - 4%206.3 ft. TF - Tap Factory Made, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open206.3 ft. RML - Roots Medium Lateral, from 06 to 11 o'clock, 10 %, within 8 inches of joint: YES216.9 ft. RML - Roots Medium Lateral, from 09 to 11 o'clock, 5 %, within 8 inches of joint: YES243 ft. RFL - Roots Fine Lateral, from 09 to 10 o'clock - 4%243 ft. TFD - Tap Factory Made Defective, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open-60% ROOTS294.4 ft. RML - Roots Medium Lateral, from 06 to 11 o'clock, 35 %, within 8 inches of joint: YES294.4 ft. TFD - Tap Factory Made Defective, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open-95% ROOTS377.5 ft. AMH - Downstream Manhole, Survey Ends - 3:00AM

Observation photos (4)

  • Roots Medium Joint, from 12 to 04 o'clock, 5 %, within 8 inches of joint: YESR

    171.9 ft. - Roots Medium Joint, from 12 to 04 o'clock, 5 %, within 8 inches of joint: YESR

  • Roots Medium Lateral, from 06 to 11 o'clock, 10 %, within 8 inches of joint: YES

    206.3 ft. - Roots Medium Lateral, from 06 to 11 o'clock, 10 %, within 8 inches of joint: YES

  • Roots Medium Lateral, from 06 to 11 o'clock, 35 %, within 8 inches of joint: YES

    294.4 ft. - Roots Medium Lateral, from 06 to 11 o'clock, 35 %, within 8 inches of joint: YES

  • Tap Factory Made Defective, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open-95% ROOTS

    294.4 ft. - Tap Factory Made Defective, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open-95% ROOTS

All inspections of P13734Work order 0793144

Observations (16)

DistanceCodeObservation
377.5AMH3:00AM
163.9RFJ4%
171.9RMJ—
243RFL4%
216.9RML—
294.4RML—
206.3TFOpen
184.3RFJ4%
294.4TFDOpen-95% ROOTS
0AMH2:25AM
153.7TFDActive-50% ROOTS
206.3RML—
0MWM—
243TFDOpen-60% ROOTS
153.7RML—
0MWL—

Properties (5)

additional_info
POST ROO EVALUATION ONLY
customer
LACSD
datetime
2019-10-30T02:25:16-07:00
documentation
MARTIN,OLIVER 111,CASTILLO
is_lateral_inspection
false
