Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 29, 2019, 11:40 AM

  • 17 0004_17 0003_10292019_044723.mp4

Date
10/29/2019
W/O
0793144
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00668
PipeID
P13729
Time
4:40 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1289R
Sewer Name
17 DISTRICT #17 MAIN TRUNK
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 17
Page No.
07
Purpose
Maintenance Related
Project
20191028MDM_DISTRICT_17_MAIN_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
17 0004
Downstream MH
17 0003
Dir. of Survey
Downstream
Length Surveyed
439.9 ft.
Total Length
439.9 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
4133
O&M Rating
20
Overall Index
2
Overall Quick
—
Overall Rating
20
Pipe schematic from manhole 17 0004 to 17 0003
MH: 17 0004MH: 17 0003downstream0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 4:40AM4.3 ft. RFJ - Roots Fine Joint, from 10 to 11 o'clock, within 8 inches of joint: YESR - 3%14.3 ft. TFD - Tap Factory Made Defective, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open-70% ROOTS14.3 ft. RML - Roots Medium Lateral, from 02 to 04 o'clock, 5 %, within 8 inches of joint: YES35.5 ft. RFJ - Roots Fine Joint, from 01 to 05 o'clock, within 8 inches of joint: YESR - 4%40 ft. RMJ - Roots Medium Joint, from 03 to 05 o'clock, 10 %, within 8 inches of joint: YESR61.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open78.5 ft. RMJ - Roots Medium Joint, from 07 to 05 o'clock, 10 %, within 8 inches of joint: YESR80.2 ft. TFD - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: YES, 5" - Open-95% ROOTS80.2 ft. RFL - Roots Fine Lateral, from 09 to 10 o'clock - 4%99.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open150.4 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open157.3 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open205.2 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open232 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open267.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open274 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open309.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open329.1 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open383.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open411 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open434.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open439.9 ft. AMH - Downstream Manhole, Survey Ends - 5:05AM

Observation photos (2)

  • Roots Medium Joint, from 03 to 05 o'clock, 10 %, within 8 inches of joint: YESR

    40 ft. - Roots Medium Joint, from 03 to 05 o'clock, 10 %, within 8 inches of joint: YESR

  • Roots Medium Joint, from 07 to 05 o'clock, 10 %, within 8 inches of joint: YESR

    78.5 ft. - Roots Medium Joint, from 07 to 05 o'clock, 10 %, within 8 inches of joint: YESR

All inspections of P13729Work order 0793144

Observations (25)

DistanceCodeObservation
0MWM—
309.3TFOpen
274TFOpen
61.3TFOpen
14.3TFDOpen-70% ROOTS
434.1TFOpen
0MWL—
40RMJ—
99.3TFOpen
150.4TFOpen
78.5RMJ—
0AMH4:40AM
329.1TFOpen
4.3RFJ3%
411TFOpen
80.2TFDOpen-95% ROOTS
205.2TFOpen
80.2RFL4%
232TFOpen
439.9AMH5:05AM
35.5RFJ4%
14.3RML—
383.9TFOpen
157.3TFOpen
267.1TFOpen

Properties (5)

additional_info
POST ROOT EVALUATION ONLY
customer
LACSD
datetime
2019-10-29T04:40:00-07:00
documentation
MARTIN,OLIVER 111,CASTILLO
is_lateral_inspection
false
