Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 28, 2019, 11:02 AM

  • 17 0013_17 0012_10282019_040357.mp4

Date
10/28/2019
W/O
0793127
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00668
PipeID
P13738
Time
4:02 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1289R
Sewer Name
17 DISTRICT #17 MAIN TRUNK
City
PASADENA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 17
Page No.
07
Purpose
Maintenance Related
Project
20191028MDM_DISTRICT_17_MAIN_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
17 0013
Downstream MH
17 0012
Dir. of Survey
Downstream
Length Surveyed
490.6 ft.
Total Length
490.6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
3423
O&M Rating
21
Overall Index
2
Overall Quick
—
Overall Rating
21
Pipe schematic from manhole 17 0013 to 17 0012
MH: 17 0013MH: 17 0012downstream0 ft. AMH - Upstream Manhole, Survey Begins - 4:15AM0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. MGO - General Observation - MH CONN 3:00 OPEN0 ft. MWL - Water Level, 15 %of cross sectional area15.3 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open39.3 ft. TB - Tap Break-In, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Open63.8 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Open112.2 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Active136.4 ft. TB - Tap Break-In, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open172.9 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Active176.8 ft. TB - Tap Break-In, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Active213 ft. TBC - Tap Break-In Capped, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Capped216.9 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Active257.2 ft. TB - Tap Break-In, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open281.8 ft. TB - Tap Break-In, at 01 o'clock, -, within 8 inches of joint: YES, 6" - Active289.7 ft. TB - Tap Break-In, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open338.3 ft. TBC - Tap Break-In Capped, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Capped354.1 ft. TBD - Tap Break-In Defective, at 02 o'clock, -, , within 8 inches of joint: YES, 6" - Active-70% ROOTS354.1 ft. RML - Roots Medium Lateral, from 01 to 04 o'clock, 10 %, within 8 inches of joint: YES356.8 ft. RFJ - Roots Fine Joint, from 08 to 04 o'clock, within 8 inches of joint: YESR - 3%383 ft. TBD - Tap Break-In Defective, at 10 o'clock, -, , within 8 inches of joint: YES, 6" - Active-70% ROOTS383 ft. RML - Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES387 ft. RFL - Roots Fine Lateral, from 02 to 04 o'clock - 4%387 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Active423.2 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - Open427.3 ft. TBC - Tap Break-In Capped, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Capped475.9 ft. TB - Tap Break-In, at 11 o'clock, -, within 8 inches of joint: YES, 6" - Open475.9 ft. RFL - Roots Fine Lateral, from 08 to 11 o'clock - 1%490.6 ft. AMH - Downstream Manhole, Survey Ends - 4:40AM

Observation photos (2)

  • Roots Medium Lateral, from 01 to 04 o'clock, 10 %, within 8 inches of joint: YES

    354.1 ft. - Roots Medium Lateral, from 01 to 04 o'clock, 10 %, within 8 inches of joint: YES

  • Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES

    383 ft. - Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES

All inspections of P13738Work order 0793127

Observations (29)

DistanceCodeObservation
338.3TBCCapped
0AMH4:15AM
289.7TBOpen
216.9TBActive
475.9TBOpen
15.3TBOpen
281.8TBActive
427.3TBCCapped
136.4TBOpen
356.8RFJ3%
354.1TBDActive-70% ROOTS
383TBDActive-70% ROOTS
63.8TBOpen
0MWM—
383RML—
213TBCCapped
112.2TBActive
257.2TBOpen
423.2TBOpen
0MGOMH CONN 3:00 OPEN
387RFL4%
490.6AMH4:40AM
39.3TBOpen
0MWL—
475.9RFL1%
172.9TBActive
176.8TBActive
354.1RML—
387TBActive

Properties (5)

additional_info
POST ROOT EVALUATION ONLY
customer
LACSD
datetime
2019-10-28T04:02:00-07:00
documentation
MARTIN,OLIVER 111,CASTILLO
is_lateral_inspection
false
