Wastewater/Activity/PacpInspection/1.0Oct 12, 2016, 10:21 AM
18 0098_18 0097 _12102016_033351.mpg
- Date
- 10/12/2016
- W/O
- 597011
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00698
- PipeID
- P13918
- Time
- 3:21 AM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3739
- Sewer Name
- 18 SANTA FE STREET TRUNK
- City
- WHITTIER, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 22
- Purpose
- Routine Assessment
- Project
- WO_597011_TV18083_OCT2016
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 18 0098
- Downstream MH
- 18 0097
- Dir. of Survey
- Downstream
- Length Surveyed
- 106 ft.
- Total Length
- 106 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (3)
0.1 ft. - Material Change, Vitrified clay pipe - MATERIAL DIFFERES FROM LACSD MAP
3.6 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
94.2 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 0.1 | MGO | CONNECITON AT MANHOLE 9 O'CLOCK |
| 94.2 | FL | — |
| 106 | AMH | 18 0097 |
| 0 | MWM | — |
| 0.1 | MMC | MATERIAL DIFFERES FROM LACSD MAP |
| 0 | AMH | 18 0098 |
| 39.9 | TFA | — |
| 106 | DAGS | — |
| 3.6 | DAGS | — |
| 43.2 | TFA | — |
| 0 | MWL | — |
Properties (6)
- additional_info
- SC303726
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-10-12T03:21:00-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
