Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Feb 2, 2017, 08:31 AM

  • J 0305_J 0304_02022017_005711.mpg

Date
02/02/2017
W/O
619078
Weather
Dry
Operator/Surveyor
R,VARGAS
Sewer ID
Z00059
PipeID
P11546
Time
12:31 AM
Certificate
U-209-211
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4103
Sewer Name
J JOINT OUTFALL J - UNIT 1G
City
RANCHO PALOS VERDES
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
41
Purpose
Routine Assessment
Project
WO_619078_TV05169_FEB2017
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
21 in.
Width
21 in.
Upstream MH
J 0304
Downstream MH
J 0305
Dir. of Survey
Upstream
Length Surveyed
420.5 ft.
Total Length
420.6 ft.
Structural Index
3
Structural Quick
3P00
Structural Rating
249
O&M Index
2
O&M Quick
2K00
O&M Rating
120
Overall Index
3
Overall Quick
—
Overall Rating
369
Pipe schematic from manhole J 0304 to J 0305
MH: J 0304MH: J 0305upstream0 ft. AMH - Upstream Manhole, Survey Ends - J 03053.4 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish3.4 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish3.4 ft. MGO - General Observation - MAGNEZIUM H.O. FINISH43.7 ft. OBZ - Obstacles Other, 10 %of cross sectional area, from 04 to 08 o'clock, Finish - DEBRIS NOT VISIBLE94.2 ft. OBZ - Obstacles Other, 10 %of cross sectional area, from 04 to 08 o'clock, Start - DEBRIS NOT VISIBLE101.2 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start101.2 ft. MGP - General Photograph272.6 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish308 ft. OBZ - Obstacles Other, 10 %of cross sectional area, from 04 to 08 o'clock - DEBRIS NOT VISIBLE418.4 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start418.4 ft. MGO - General Observation - MAGNESIUM H.O. START418.4 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start420.6 ft. AMH - Downstream Manhole, Survey Begins - J 0304420.6 ft. MWM - Water Mark, 25 %of cross sectional area420.6 ft. MWL - Water Level, 15 %of cross sectional area

Observation photos (4)

  • Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2.2 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.2 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    319.4 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • General Photograph

    319.4 ft. - General Photograph

All inspections of P11546Work order 619078

Observations (16)

DistanceCodeObservation
148DAGS—
319.4DAGS—
0AMHJ 0304
376.9OBZDEBRIS NOT VISIBLE
417.2DAGS—
319.4MGP—
417.2SAV—
0MWM—
2.2DAGS—
2.2MGOMAGNESIUM H.O. START
112.6OBZDEBRIS NOT VISIBLE
326.4OBZDEBRIS NOT VISIBLE
2.2SAV—
417.2MGOMAGNEZIUM H.O. FINISH
0MWL—
420.6AMHJ 0305

Properties (6)

additional_info
SC318645
custom_field_two
3
customer
LACSD
datetime
2017-02-02T00:31:37-08:00
documentation
PRO PIPE
is_lateral_inspection
false
