Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 30, 2017, 11:11 AM

  • 20 0136_20 0135 _01302017_033022.mp4

Date
01/30/2017
W/O
618961
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00744
PipeID
P19059
Time
3:11 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4224
Sewer Name
20 TRUNK "C"
City
PALMDALE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 20
Page No.
01
Purpose
Routine Assessment
Project
WO_618961_TV20027_FEB2017
Sewer Type
Gravity
Material
NRCP
Shape
Circular
Height
12 in.
Width
12 in.
Upstream MH
20 0135
Downstream MH
20 0136
Dir. of Survey
Upstream
Length Surveyed
2 ft.
Total Length
2 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
4
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole 20 0135 to 20 0136
MH: 20 0135MH: 20 0136upstream0 ft. MSA - Survey Abandoned - DUE TO OBSTACLE0 ft. OBR - Obstacles Rocks, 25 %of cross sectional area, from 05 to 08 o'clock2 ft. MGO - General Observation - ACTIVE CONNECTION AT MH 9 O'CLOCK2 ft. AMH - Downstream Manhole, Survey Begins - 20 0135

Observation photos (2)

  • Survey Abandoned - DUE TO OBSTACLE

    2 ft. - Survey Abandoned - DUE TO OBSTACLE

  • Obstacles Rocks, 25 %of cross sectional area, from 05 to 08 o'clock

    2 ft. - Obstacles Rocks, 25 %of cross sectional area, from 05 to 08 o'clock

All inspections of P19059Work order 618961

Observations (4)

DistanceCodeObservation
0MGOACTIVE CONNECTION AT MH 9 O'CLOCK
0AMH20 0135
2MSADUE TO OBSTACLE
2OBR—

Properties (6)

additional_info
SC306726
custom_field_two
5
customer
LACSD
datetime
2017-01-30T03:11:28-08:00
documentation
PRO PIPE
is_lateral_inspection
false
