Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 30, 2018, 11:08 AM

  • C 0301_C 0300 _30042018_042025.mp4

Date
04/30/2018
W/O
696324
Weather
Dry
Operator/Surveyor
B FUGATE
Sewer ID
Z00134
PipeID
P09761
Time
4:08 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K5545
Sewer Name
C JOINT OUTFALL C - UNIT 6E
City
CERRITOS
Loc. details
Easement/Right of Way
Location Code
D
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
04
Purpose
Routine Assessment
Project
WO_696324_TV19035_APR2018
Sewer Type
Gravity
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Width
24 in.
Upstream MH
C 0301
Downstream MH
C 0300
Dir. of Survey
Downstream
Length Surveyed
200.6 ft.
Total Length
200.6 ft.
Structural Index
3
Structural Quick
3100
Structural Rating
3
O&M Index
3
O&M Quick
3121
O&M Rating
5
Overall Index
3
Overall Quick
—
Overall Rating
8
Pipe schematic from manhole C 0301 to C 0300
MH: C 0301MH: C 0300downstream0 ft. AMH - Upstream Manhole, Survey Begins - C 03010 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MWL - Water Level, 15 %of cross sectional area2.7 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start34.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"42 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"78.7 ft. ID - Infiltration Dripper, at 12 o'clock, within 8 inches of joint: NO82.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"90.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"129.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"137.5 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"178 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"185.7 ft. TBC - Tap Break-In Capped, at 02 o'clock, -, within 8 inches of joint: NO, 6"200.6 ft. MGO - General Observation - SERVICE CONNECTION AT 9 O'CLOCK AT MH200.6 ft. AMH - Downstream Manhole, Survey Ends - C 0300200.6 ft. SAP - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish

Observation photos (2)

  • Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    2.7 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Infiltration Dripper, at 12 o'clock, within 8 inches of joint: NO

    78.7 ft. - Infiltration Dripper, at 12 o'clock, within 8 inches of joint: NO

All inspections of P09761Work order 696324

Observations (16)

DistanceCodeObservation
200.6MGOSERVICE CONNECTION AT 9 O'CLOCK AT MH
0AMHC 0301
200.6AMHC 0300
0MWM—
82.2TFC—
200.6SAP—
42TFC—
178TFC—
0MWL—
137.5TFC—
185.7TBC—
34.1TFC—
129.5TFC—
90.5TFC—
78.7ID—
2.7SAP—

Properties (6)

additional_info
SC359303
custom_field_two
3
customer
LACSD
datetime
2018-04-30T04:08:52-07:00
documentation
PROPIPE
is_lateral_inspection
false
