Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 7, 2019, 10:58 AM

  • Section#1_01 0276_01 0243__1072019__I0264.mp4

Date
10/07/2019
W/O
0794608
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00219
PipeID
P01324
Time
3:58 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
I0264
Sewer Name
01 STANFORD AVENUE TRUNK
City
WILLBROOK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
12
Purpose
Maintenance Related
Project
20191007MDM_STANFORD_AVENUE_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
01 0276
Downstream MH
01 0243
Dir. of Survey
Downstream
Length Surveyed
5.9 ft.
Total Length
6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 01 0276 to 01 0243
MH: 01 0276MH: 01 0243downstream0 ft. MGO - General Observation - MH CONN 9:00 ACTIVE0 ft. AMH - Upstream Manhole, Survey Begins - 4:05AM0 ft. MGO - General Observation - MH C0NN 3:00 ACTIVE0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. MWM - Water Mark, 30 %of cross sectional area5.4 ft. MGO - General Observation - 4 DROP CONN 6:005.4 ft. MGO - General Observation - 2 DROP CONN 6:005.4 ft. MGO - General Observation - 5 DROP CONN 6:005.4 ft. MGO - General Observation - 1 DROP CONN 6:005.4 ft. MGO - General Observation - 6 DROP CONN 6:005.4 ft. MGO - General Observation - 3 DROP CONN 6:005.5 ft. MGO - General Observation - 7 OPENING BOTTOM OF CHANNEL-SUMP MH5.6 ft. MGO - General Observation - 8 CHANNEL UNDER PIPE TO MH SUMP6 ft. MSA - Survey Abandoned - 5:35AM MH TO 5.5' INSPECTION COMPLETED

Observation photos (8)

  • General Observation - 4 DROP CONN 6:00

    5.4 ft. - General Observation - 4 DROP CONN 6:00

  • General Observation - 2 DROP CONN 6:00

    5.4 ft. - General Observation - 2 DROP CONN 6:00

  • General Observation - 5 DROP CONN 6:00

    5.4 ft. - General Observation - 5 DROP CONN 6:00

  • General Observation - 1 DROP CONN 6:00

    5.4 ft. - General Observation - 1 DROP CONN 6:00

  • General Observation - 6 DROP CONN 6:00

    5.4 ft. - General Observation - 6 DROP CONN 6:00

  • General Observation - 3 DROP CONN 6:00

    5.4 ft. - General Observation - 3 DROP CONN 6:00

  • General Observation - 7 OPENING BOTTOM OF CHANNEL-SUMP MH

    5.5 ft. - General Observation - 7 OPENING BOTTOM OF CHANNEL-SUMP MH

  • General Observation - 8 CHANNEL UNDER PIPE TO MH SUMP

    5.6 ft. - General Observation - 8 CHANNEL UNDER PIPE TO MH SUMP

All inspections of P01324Work order 0794608

Observations (14)

DistanceCodeObservation
0MGOMH CONN 9:00 ACTIVE
5.4MGO4 DROP CONN 6:00
0AMH4:05AM
0MGOMH C0NN 3:00 ACTIVE
5.4MGO2 DROP CONN 6:00
5.5MGO7 OPENING BOTTOM OF CHANNEL-SUMP MH
0MWL—
0MWM—
5.4MGO5 DROP CONN 6:00
5.4MGO1 DROP CONN 6:00
5.4MGO6 DROP CONN 6:00
5.4MGO3 DROP CONN 6:00
6MSA5:35AM MH TO 5.5' INSPECTION COMPLETED
5.6MGO8 CHANNEL UNDER PIPE TO MH SUMP

Properties (5)

additional_info
APPOX 5' DOWNSTREAM MH 276 AT 6:00 HOLE OR DROP CONN
customer
LACSD
datetime
2019-10-07T03:58:02-07:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
