Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 8, 2019, 08:09 AM

  • Section#5_17 0073_17 0072__1082019__I0265R.mp4

Date
10/08/2019
W/O
0795377
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00668
PipeID
P13792
Time
1:09 AM
Certificate
1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
I0265R
Sewer Name
17 DISTRICT #17 MAIN TRUNK
City
PASADENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 17
Page No.
06
Purpose
Maintenance Related
Project
20191003MDM_DISTRICT_17_MAIN_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
17 0073
Downstream MH
17 0072
Dir. of Survey
Downstream
Length Surveyed
342.8 ft.
Total Length
342.8 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
412L
O&M Rating
139
Overall Index
2
Overall Quick
—
Overall Rating
139
Pipe schematic from manhole 17 0073 to 17 0072
MH: 17 0073MH: 17 0072downstream0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. MWM - Water Mark, 40 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:10AM16.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start173.7 ft. RFJ - Roots Fine Joint, from 09 to 12 o'clock, within 8 inches of joint: YESR - 1%258.9 ft. RFJ - Roots Fine Joint, from 08 to 12 o'clock, within 8 inches of joint: YESR - 2%260.4 ft. TB - Tap Break-In, at 02 o'clock, -, within 8 inches of joint: YES, 6" - OPEN263.5 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - STUB263.5 ft. MWM - Water Mark, 60 %of cross sectional area271.2 ft. RFJ - Roots Fine Joint, from 09 to 03 o'clock, within 8 inches of joint: YESR - 1%308.7 ft. DSZ - Deposits Settled Other, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES - ROCK342.4 ft. MGO - General Observation - MH CONN 9:00 ACTIVE342.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish342.8 ft. AMH - Downstream Manhole, Survey Ends - 1:35AM

Observation photos (1)

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    16.6 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

All inspections of P13792Work order 0795377

Observations (14)

DistanceCodeObservation
263.5TFCSTUB
342.8AMH1:35AM
342.4MGOMH CONN 9:00 ACTIVE
0MWL—
16.6DAGS—
263.5MWM—
173.7RFJ1%
0MWM—
308.7DSZROCK
260.4TBOPEN
271.2RFJ1%
342.4DAGS—
258.9RFJ2%
0AMH1:10AM

Properties (5)

additional_info
ROOT EVALUATION ONLY
customer
LACSD
datetime
2019-10-08T01:09:01-07:00
documentation
MARTIN,REVELES,OLIVER 111,CASTILLO
is_lateral_inspection
false
