Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 4, 2019, 08:42 AM

  • C 0192_C 0610_942019_015300.mp4

Date
09/04/2019
W/O
0771977
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00124
PipeID
P22822
Time
1:42 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H1265
Sewer Name
C JOINT OUTFALL C - UNIT 3E
City
LONG BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
19
Purpose
Capital Improvement Program Assesment
Project
20190904MDM_JOINT_OUTFALL_C_UNIT_3E
Material
Reinforced Concrete Pipe
Shape
Circular
Height
22.5 in.
Upstream MH
C 0192
Downstream MH
C 0610
Dir. of Survey
Downstream
Length Surveyed
239.7 ft.
Total Length
239.7 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
3
O&M Quick
5242
O&M Rating
29
Overall Index
3
Overall Quick
—
Overall Rating
29
Pipe schematic from manhole C 0192 to C 0610
MH: C 0192MH: C 0610downstream0 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active0 ft. MWM - Water Mark, 60 %of cross sectional area0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:55AM0 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active3 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO8 ft. DSZ - Deposits Settled Other, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start - SLUDGE, DEBRIE9 ft. MGO - General Observation - 22.50 RCP + FR POLY LINE20.4 ft. DAGS - Deposits Attached Grease, 15 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO, Start20.4 ft. MWM - Water Mark, 100 %of cross sectional area90.8 ft. DAGS - Deposits Attached Grease, 15 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO, Finish90.8 ft. MWL - Water Level, 70 %of cross sectional area107.6 ft. MWM - Water Mark, 90 %of cross sectional area137.6 ft. DSZ - Deposits Settled Other, 10 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: NO - ROCK215.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO234.8 ft. MWL - Water Level, 80 %of cross sectional area239 ft. DSZ - Deposits Settled Other, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Finish - SLUDGE , DEBRIE239 ft. DSZ - Deposits Settled Other, 25 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: NO - SLUDGE239.7 ft. MSA - Survey Abandoned - 25% SLUDGE STOPPED CAMERA

Observation photos (4)

  • General Observation - 22.50 RCP + FR POLY LINE

    9 ft. - General Observation - 22.50 RCP + FR POLY LINE

  • Deposits Attached Grease, 15 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO, Start

    20.4 ft. - Deposits Attached Grease, 15 %of cross sectional area, from 11 to 01 o'clock, , within 8 inches of joint: NO, Start

  • Water Mark, 90 %of cross sectional area

    107.6 ft. - Water Mark, 90 %of cross sectional area

  • Deposits Settled Other, 10 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: NO - ROCK

    137.6 ft. - Deposits Settled Other, 10 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: NO - ROCK

All inspections of P22822Work order 0771977

Observations (19)

DistanceCodeObservation
137.6DSZROCK
90.8DAGS—
0MGOConn. @ Mh, 3 O' Clock. Active
239.7MSA25% SLUDGE STOPPED CAMERA
9MGO22.50 RCP + FR POLY LINE
234.8MWL—
215.6DAGS—
3DAGS—
107.6MWM—
0MWM—
239DSZSLUDGE , DEBRIE
0MWL—
0AMH1:55AM
20.4DAGS—
90.8MWL—
239DSZSLUDGE
8DSZSLUDGE, DEBRIE
0MGOConn. @ Mh, 9 O' Clock. Active
20.4MWM—

Properties (5)

customer
LACSD
datetime
2019-09-04T01:42:24-07:00
documentation
MARTIN,REVELES,OLIVER 111,BRAR
is_lateral_inspection
false
lining
FR POLY LINE
