Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Oct 24, 2016, 11:34 AM

  • A 0320_A 0319_10242016_044458.mp4

Date
10/24/2016
W/O
0602872
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00325
PipeID
P08230
Time
4:34 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G6746
Sewer Name
A JOA-1A SAN JOSE CREEK WRP INTERCEPTOR
City
EI MONTE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
16
Purpose
Routine Assessment
Project
20161021MDM_JOA_1A_SAN_JOSE_CREEK_WRP_INTERCEPTOR
Material
FIBERGLASS
Shape
Circular
Height
12 in.
Upstream MH
A 0320
Downstream MH
A 0319
Dir. of Survey
Downstream
Length Surveyed
18.1 ft.
Total Length
18.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole A 0320 to A 0319
MH: A 0320MH: A 0319downstream0 ft. AMH - Upstream Manhole, Survey Begins - 4:40AM0 ft. MWL - Water Level, 0 %of cross sectional area - DRY LINE0 ft. MWM - Water Mark, 0 %of cross sectional area7.9 ft. MGP - General Photograph - 12" FIBERGLASS8 ft. MGO - General Observation - 12" FIBERGLASS18.1 ft. AMH - Downstream Manhole, Survey Ends MH IS LOCAL MH - 4:50AM

Observation photos (3)

  • General Photograph - 12" FIBERGLASS

    7.9 ft. - General Photograph - 12" FIBERGLASS

  • General Observation - 12" FIBERGLASS

    8 ft. - General Observation - 12" FIBERGLASS

  • Downstream Manhole, Survey Ends MH IS LOCAL MH - 4:50AM

    18.1 ft. - Downstream Manhole, Survey Ends MH IS LOCAL MH - 4:50AM

All inspections of P08230Work order 0602872

Observations (6)

DistanceCodeObservation
18.1AMH4:50AM
7.9MGP12" FIBERGLASS
8MGO12" FIBERGLASS
0AMH4:40AM
0MWLDRY LINE
0MWM—

Properties (5)

additional_info
AIRLINE MH A 0320 TO LOCAL MH
customer
LACSD
datetime
2016-10-24T04:34:58-07:00
documentation
MARTIN,MANANES,REVELES,OLIVER 111
is_lateral_inspection
false
