Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0May 31, 2018, 03:53 PM

  • A 0305_A 0304_5312018_102829.mp4

Date
05/31/2018
W/O
0706684
Weather
Dry
Operator/Surveyor
SANTIAGO OBREGON
Sewer ID
Z00325
PipeID
P08215
Time
8:53 AM
Certificate
U-1014-06022541
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7722
Sewer Name
A JOA-1A SAN JOSE CREEK WRP INTERCEPTOR
City
SOUTH EL MONTE
Loc. details
Creek
Location Code
K
Use of Sewer
Sanitary Sewer
District
District 15
Page No.
33
Purpose
Capital Improvement Program Assesment
Project
20180531SHO_JOA1A_SAN_JOSE_CREEK_WRP_INTERCEPTOR
Material
Reinforced Concrete Pipe
Shape
Circular
Height
63 in.
Upstream MH
A 0305
Downstream MH
A 0304
Dir. of Survey
Downstream
Length Surveyed
1056.4 ft.
Total Length
1056.4 ft.
Structural Index
3
Structural Quick
5131
Structural Rating
9
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
3
Overall Quick
—
Overall Rating
13
Pipe schematic from manhole A 0305 to A 0304
MH: A 0305MH: A 0304downstream0 ft. MWM - Water Mark, 55 %of cross sectional area0 ft. MWL - Water Level, 50 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 10309 ft. MGO - General Observation - 90% MAG COAT INTACT45 ft. SRI - Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Start1053.5 ft. SAV - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES1053.5 ft. SRI - Surface Roughness Increased, from 09 to 03 o'clock, within 8 inches of joint: YES, Finish1056.2 ft. SRV - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES1056.4 ft. AMH - Downstream Manhole, Survey Ends - 1115

Observation photos (2)

  • Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES

    1053.5 ft. - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES

    1056.2 ft. - Surface Reinforcement Visible, from 09 to 03 o'clock, within 8 inches of joint: YES

All inspections of P08215Work order 0706684

Observations (9)

DistanceCodeObservation
0MWM—
9MGO90% MAG COAT INTACT
0MWL—
1053.5SAV—
0AMH1030
45SRI—
1056.2SRV—
1056.4AMH1115
1053.5SRI—

Properties (8)

additional_info
RFIR
custom_field_three
VISIBLE REBAR AT THE END OF THE REACH
custom_field_two
2
customer
LACSD
datetime
2018-05-31T08:53:15-07:00
documentation
OBREGON, BRAR, VENDRYES, PARAISO
is_lateral_inspection
false
year_laid
19790427
