Wastewater/Activity/PacpInspection/1.0Jun 5, 2019, 06:34 AM
18 0096_18 0095 _06042019_234622.mp4
- Date
- 06/04/2019
- W/O
- 766605
- Weather
- Dry
- Operator/Surveyor
- J. BUENROSTRO
- Sewer ID
- Z00698
- PipeID
- P13916
- Time
- 11:34 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K6559
- Sewer Name
- 18 SANTA FE STREET TRUNK
- City
- WHITTIER
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 18
- Page No.
- 21
- Purpose
- Routine Assessment
- Project
- WO_766605_TV18083_MAY2019
- Sewer Type
- Gravity
- Material
- NRCP
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 18 0096
- Downstream MH
- 18 0095
- Dir. of Survey
- Downstream
- Length Surveyed
- 287.4 ft.
- Total Length
- 287.4 ft.
- Structural Index
- 3
- Structural Quick
- 3K2J
- Structural Rating
- 283
- O&M Index
- 2
- O&M Quick
- 2J00
- O&M Rating
- 112
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 395
Observation photos (3)
4 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
4 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
20.1 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (14)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 0 | MWM | — |
| 0 | CM | — |
| 0 | MGO | ROACHES @ MH |
| 20.1 | SSS | — |
| 285.4 | SAP | — |
| 287.4 | AMH | 18 0095 |
| 285.4 | SSS | — |
| 0 | AMH | 18 0096 |
| 4 | SAP | — |
| 182.3 | TB | OPEN |
| 284 | CM | — |
| 4 | DAGS | — |
| 285.4 | DAGS | — |
Properties (6)
- additional_info
- SC377681
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2019-06-04T23:34:28-07:00
- documentation
- PROPIPE
- is_lateral_inspection
- false
