Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jun 5, 2019, 05:34 AM

  • 18 0099_18 0098 _06042019_225717.mp4

Date
06/04/2019
W/O
766605
Weather
Dry
Operator/Surveyor
J. BUENROSTRO
Sewer ID
Z00698
PipeID
P13919
Time
10:34 PM
Certificate
U-715-07000770
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K6559
Sewer Name
18 SANTA FE STREET TRUNK
City
WHITIER
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
22
Purpose
Routine Assessment
Project
WO_766605_TV18083_MAY2019
Sewer Type
Gravity
Material
VCP
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
18 0099
Downstream MH
18 0098
Dir. of Survey
Downstream
Length Surveyed
194.7 ft.
Total Length
194.7 ft.
Structural Index
3
Structural Quick
3M2G
Structural Rating
282
O&M Index
2
O&M Quick
2200
O&M Rating
4
Overall Index
3
Overall Quick
—
Overall Rating
286
Pipe schematic from manhole 18 0099 to 18 0098
MH: 18 0099MH: 18 0098downstream0 ft. MGO - General Observation - ROACHES @ MH0 ft. MGO - General Observation - PIPE MATERIAL IS VCP0 ft. AMH - Upstream Manhole, Survey Begins - 18 00990 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 20 %of cross sectional area2 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start2 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start4.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start23.1 ft. FS - Fracture Spiral, from 09 to 12 o'clock, within 8 inches of joint: YES39.8 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6" - OPEN41.4 ft. CS - Crack Spiral, from 04 to 10 o'clock, within 8 inches of joint: YES51.6 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start63 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6" - OPEN100.4 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 6" - OPEN128.3 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6" - OPEN159.6 ft. FS - Fracture Spiral, from 02 to 10 o'clock, within 8 inches of joint: YES186.1 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 6" - OPEN192.4 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish192.4 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish193 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish193 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish193.9 ft. MGO - General Observation - CONNECTION IN MH 3 OCLOCK/OPEN194 ft. MGO - General Observation - ROACHES@ MH194.7 ft. AMH - Downstream Manhole, Survey Ends - 18 0098

Observation photos (5)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    4.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Fracture Spiral, from 09 to 12 o'clock, within 8 inches of joint: YES

    23.1 ft. - Fracture Spiral, from 09 to 12 o'clock, within 8 inches of joint: YES

  • Crack Spiral, from 04 to 10 o'clock, within 8 inches of joint: YES

    41.4 ft. - Crack Spiral, from 04 to 10 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    51.6 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Fracture Spiral, from 02 to 10 o'clock, within 8 inches of joint: YES

    159.6 ft. - Fracture Spiral, from 02 to 10 o'clock, within 8 inches of joint: YES

All inspections of P13919Work order 766605

Observations (24)

DistanceCodeObservation
2CM—
194MGOROACHES@ MH
51.6CM—
193.9MGOCONNECTION IN MH 3 OCLOCK/OPEN
63TFOPEN
0MGOROACHES @ MH
192.4DAGS—
39.8TFOPEN
128.3TFOPEN
186.1TFOPEN
2SSS—
193SSS—
4.5DAGS—
0MGOPIPE MATERIAL IS VCP
100.4TFOPEN
159.6FS—
0AMH18 0099
0MWM—
192.4CM—
23.1FS—
194.7AMH18 0098
0MWL—
193CM—
41.4CS—

Properties (6)

additional_info
SC377681
custom_field_two
3
customer
LACSD
datetime
2019-06-04T22:34:48-07:00
documentation
PROPIPE
is_lateral_inspection
false
