Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jul 30, 2019, 03:57 PM

  • A 0911_18 0433_7302019_091429.mp4

Date
07/30/2019
W/O
0767446
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00675
PipeID
P14282
Time
8:57 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G8040
Sewer Name
18 FLORENCE AVENUE TRUNK
City
SANTE FE SPRINGS
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 18
Page No.
19
Purpose
Routine Assessment
Project
20190730DF_FLORENCE_AVENUE_TRUNK
Material
Reinforced Concrete Pipe
Shape
Circular
Height
27 in.
Upstream MH
18 0433
Downstream MH
A 0911
Dir. of Survey
Upstream
Length Surveyed
2.1 ft.
Total Length
2.1 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 18 0433 to A 0911
MH: 18 0433MH: A 0911upstream0 ft. AMH - Upstream Manhole, Survey Ends - 9:21 AM0.1 ft. MGP - General Photograph0.1 ft. MGO - General Observation - BULK HEAD2 ft. MWL - Water Level, 5 %of cross sectional area2 ft. MWM - Water Mark, 10 %of cross sectional area2 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active2.1 ft. AMH - Downstream Manhole, Survey Begins - 8:59 AM

Observation photos (3)

  • General Observation - Conn. @ Mh, 9 O' Clock. Active

    0.1 ft. - General Observation - Conn. @ Mh, 9 O' Clock. Active

  • General Photograph

    2 ft. - General Photograph

  • General Observation - BULK HEAD

    2 ft. - General Observation - BULK HEAD

All inspections of P14282Work order 0767446

Observations (7)

DistanceCodeObservation
0.1MWL—
2MGP—
2.1AMH9:21 AM
0.1MWM—
2MGOBULK HEAD
0.1MGOConn. @ Mh, 9 O' Clock. Active
0AMH8:59 AM

Properties (5)

custom_field_two
3
customer
LACSD
datetime
2019-07-30T08:57:28-07:00
documentation
FRANKLIN, IGNACIO, RUVALCABA, CASTILLO
is_lateral_inspection
false
