Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 5, 2019, 12:16 PM

  • Section#6_02 2076_02 2075__852019__I0205.mp4

Date
08/05/2019
W/O
0785336
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00241
PipeID
P04284
Time
5:16 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
I0205
Sewer Name
02 CITY TERRACE TRUNK
City
LOS ANGLES
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
07A
Purpose
Routine Assessment
Project
20190802MDM_CITY_TERRACE_TRUNK
Material
Reinforced Concrete Pipe
Shape
Circular
Height
21 in.
Upstream MH
02 2076
Downstream MH
02 2075
Dir. of Survey
Downstream
Length Surveyed
224.6 ft.
Total Length
224.6 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 02 2076 to 02 2075
MH: 02 2076MH: 02 2075downstream0 ft. MWM - Water Mark, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 5:20AM0 ft. MWL - Water Level, 5 %of cross sectional area2 ft. MGO - General Observation - 100% MAG COAT START13.4 ft. MGO - General Observation - ROUGH TEXTURED CONCRETE UNDER MAG COAT17 ft. MGO - General Observation - GOOD CONDITION CONCRETE106.6 ft. MGO - General Observation - 100% MAG COAT224.3 ft. MGO - General Observation - 100% MAG COAT FINISH224.6 ft. AMH - Downstream Manhole, Survey Ends - 5:35AM

Observation photos (4)

  • General Observation - 100% MAG COAT START

    2 ft. - General Observation - 100% MAG COAT START

  • General Observation - ROUGH TEXTURED CONCRETE UNDER MAG COAT

    13.4 ft. - General Observation - ROUGH TEXTURED CONCRETE UNDER MAG COAT

  • General Observation - GOOD CONDITION CONCRETE

    17 ft. - General Observation - GOOD CONDITION CONCRETE

  • General Observation - 100% MAG COAT

    106.6 ft. - General Observation - 100% MAG COAT

All inspections of P04284Work order 0785336

Observations (9)

DistanceCodeObservation
0MWM—
224.3MGO100% MAG COAT FINISH
2MGO100% MAG COAT START
17MGOGOOD CONDITION CONCRETE
0AMH5:20AM
13.4MGOROUGH TEXTURED CONCRETE UNDER MAG COAT
106.6MGO100% MAG COAT
224.6AMH5:35AM
0MWL—

Properties (6)

custom_field_three
GOOD CONDITION CONCRETE UNDER MAG COAT
custom_field_two
4
customer
LACSD
datetime
2019-08-05T05:16:29-07:00
documentation
MARTIN,,REVELES,OLIVER 111,BRAR
is_lateral_inspection
false
